Monthly Visual Inspection
FIGURE 1-19. Tailgate safety pin, cylinder, and safety prop
1.5.4

Visual Inspection on the Body

Always set the safety prop after opening the tailgate.
To perform the visual inspection on the body:
1. Perform visual inspection procedure preparation, see
2. Bring the loading buckets up and set the safety pin in the rails. Open the tailgate and
set the safety prop.
FIGURE 1-20. Loading bucket safety pin and tailgate safety prop
3. Apply the lockout/tagout procedure for the rest of the truck.
Top Select Maintenance Manual
T
AILGATE SAFETY PIN
section 1.5 on page 26.
1-31
