Maximizer Maintenance
8. Set the Maximizer on blocks so you can pick it up again with the fork lift later on.
T
HOROUGLY SOAK PAPER STUCK BETWEEN THE
PERFORMING ANY REPAIR WITH A WELDING DEVICE OR ANY HEAT SOURCE
To reinstall the Maximizer:
1. Use the same forklift you used to remove the Maximizer to bring it to the body and
align it so it can be slid in.
2. Attach the Maximizer with a chain through the roof opening to a lifting device.
3. Once it is safely attached, release it from the forklift and slide it in with the lifting
device to set it on the rails.
FIGURE 2-10. Maximizer rails
4. Move the Maximizer to meet the head and align the two structures.
5. Weld the head to the rest of the Maximizer.
2-16
WARNING
M
M
AXIMIZER RAILS
AXIMIZER AND THE BODY BEFORE
