Loading Container Maintenance

1.6 Loading Container Maintenance
In this section you find the maintenance procedures related to the loading container and
its components.
1.6.1

General Maintenance on the Loading Container

Safe operation of the loading container is very important. On a daily basis, check all pin
joints for missing anchor bolts and cotter pins. Verify all critical welds on the lifting arms
of applicable models. Check the linkages for loose lock collars or nuts or bad threads;
replace or repair immediately all faulty items. Call factory for any structural problem that
may endanger the operator's safety.
N : A
OTE FTER THE LOCK NUT IS PROPERLY TORQUED
TOGETHER
FIGURE 1-25. Different types of linkages
Top Select Maintenance Manual
.
M
ODEL WITH A
CLAMP
,
TACK WELD MAIN NUT AND LOCK NUT
M
ODEL WITH A
COUNTERNUT
