Labrie Top Select Maintenance Manual page 33

Top Select Maintenance Guide
V
ISUAL INSPECTION OF THE LOADING BUCKET
Two rods between the bucket and the cylinder; verify linkages, loose lock nut or bad
•
threads. Check all missing anchor bolts or cotter pin. For rod maintenance and
repair, see section 1.6.5 on page
FIGURE 1-15.
One optional automatic cart latch; make sure the the manual release slide easily.
•
Verify if the bearing that hits the latch turns freely. That bearing must be close
enough to the latch to allow efficient movement of the latching system, otherwise it
will need adjustment. See
wear. Look inside the bucket at the ball joint's level and inspect the pin joint.
3. Move the second bucket if you have a Top Select 2000.
FIGURE 1-16. Automatic latch inspection
1-28
40.
section 1.6.9 on page
(C
ONTINUED
46. Check the ball joint for unusual
Top Select Maintenance Manual
)
