MICRO-EPSILON surfaceCONTROL 3D Instruction Manual page 47

Working with 3DInspect
4 Desired configuration: Use the following input fields to enter the network configuration for the se-
lected sensor:
- IP address: IP address
- Subnet mask: Subnet mask
- Default gateway: Default gateway
- Static IP: "Static IP" option – if this option is enabled, dynamic address allocation is disabled.
The IP address entered is used as IP address. This parameter takes precedence over the
"DHCP" and "Link local address" options.
- DHCP: "DHCP" option – if this option is enabled, the IP address is allocated dynamically
through a DHCP server. This parameter takes precedence over "Link local address". This option
is always enabled.
- Link local address: "Link local address" option – if this option is enabled, the IP address is allo-
cated dynamically in the local subnet 169.254.x.x. This option is always enabled.
5 Suggest a configuration: Click this button to have a suitable configuration for the selected sensor
determined automatically. After the process is complete, the system automatically completes the
input fields in the "Desired configuration" section.
6 Apply to selected device: Click this button to apply the network configuration specified in the "De-
sired configuration" section to the selected sensor.
Proceed as follows to manually enter the network configuration parameters for a sensor:
When the "Ethernet Configurator" dialog is opened, the system automatically searches for available
sensors. If the sensor is not connected to your subnet yet, establish a connection, and click the
"Scan" button. When scanning is complete, the sensor is displayed in the device list.
Select the required sensor from the device list.
Specify the required network settings in the input fields in the "Desired configuration" section.
Click "Apply to selected device" to apply the settings to the selected sensor.
Click OK to confirm the selections in the "Ethernet Configurator" dialog.
Proceed as follows to automatically specify network configuration parameters for a sensor:
When the "Ethernet Configurator" dialog is opened, the system automatically searches for available
sensors. If the sensor is not connected to your subnet yet, establish a connection, and click the
"Scan" button. When scanning is complete, the sensor is displayed in the device list.
Select the required sensor from the device list.
Click the "Suggest a configuration" button to have a suitable network configuration for the selected
sensor determined automatically. After the process is complete, the system automatically com-
pletes the input fields in the "Desired configuration" section.
Click "Apply to selected device" to apply the settings to the selected sensor.
Click OK to confirm the selections in the "Ethernet Configurator" dialog.
