Working with 3DInspect
measuring programs, but not the other way round ("waterfall model"). The dependencies of the currently
selected measuring program on other measuring programs are represented graphically as arrows.
Fig. 3.32: List of active measuring programs ("Evaluation" view)
-
Adding a measuring program:
Click on the "+" button (see Fig. 3.32).
A drop-list of available measuring programs appears in the relevant region:
Fig. 3.33: List of measuring programs
Click on the desired measuring program and then on "Add program", or double-click on the
desired program in order to add it to the list of active measuring programs.
You can add other measuring programs if desired.
Confirm the dialog with OK.
The selected programs have now been added to the end of the list of measuring programs and the
measuring program added last is selected.
-
Removing a measuring program:
Select the measuring program you want to remove from the list.
Click on the "-" button (see Fig. 3.32).
The selected measuring program is removed from the list of active measuring programs.
