Microscan VS-1 Getting Started page 65

FIGURE 3–8.
Select Edge Line:EdgeLine from Left Fast Edge.
31.
Click OK.
32.
To select the reference for Second Line, click in the area to the right
33.
of the blue arrow (Figure 3–9), and click on the three dots, which
displays the Select Reference window, as shown in Figure 3–10.
FIGURE 3–9.
v4.1.0, February 2010
Select Reference Window
Selecting Reference for Second Line
Getting Started with the VS-1 Smart Camera
Advanced Example Using Multiple Tools
Click Here
3
3-9
