Microscan VS-1 Getting Started page 39

FIGURE 2–22.
Highlight Right Fast Edge in the Step Tree (left pane).
26.
Adjust the following Right Fast Edge properties:
27.
–
–
–
Highlight Snapshot in the Step Tree (left pane). Right click Snapshot
28.
and click Insert Into. FrontRunner™ displays the Insert Step window.
Double click on Fast Edge Tool to insert a fourth one into the
Snapshot.
Highlight Fast Edge in the Step Tree (left pane), right click, and then
29.
click Rename. Rename it to Bottom Fast Edge.
Adjust the ROI for Bottom Fast Edge so that it looks like the image in
30.
Figure 2–23.
v4.1.0, February 2010
Chip01.tif with Three Fast Edge Tool Adjusted
Scan Direction — Set to Right to Left
Transition color — Set to Light to Dark
Gradient Threshold — Set to 50
Getting Started with the VS-1 Smart Camera
Simple Fast Edge Tool
2-25
2
