Microscan VS-1 Getting Started page 21

FIGURE 2–4.
To run the job once and then stop, click
15.
The Job passes.
In the left pane of the Editor, highlight Acquire.
16.
FrontRunner™ displays the Acquire properties page.
Adjust the following Acquire properties:
17.
–
Select die2pip.tif through die6pip.tif and click Open.
18.
Minimize the Editor.
19.
To run the job once and then stop, click
20.
Notice that NumBlobs matches the number of pips on the die, as
21.
shown in Figure 2–5.
v4.1.0, February 2010
Blob Tool ROI Moved and Sized
File List — Click to the right of File List, and then click Add....
Browse for the files die2pip.tif, die3pip.tif, die4pip.tif, die5pip.tif,
and die6pip.tif from Windows. They are located at:
C:\Vscape\Tutorials & Samples\Tutorials\HawkEye 1600T\Simple
Blob Tool
Getting Started with the VS-1 Smart Camera
Simple Blob Tool
.
.
2-7
2
