Highlight Snapshot in the Step Tree. Right click Snapshot and click
9.
Insert Into. FrontRunner™ displays the Insert Step window. Double
click on Blob Tool to insert it into the Snapshot.
In the left pane, highlight Blob Filter in the Step Tree. Right click Blob
10.
Filter and click Delete. FrontRunner™ displays the Are you sure you
want to delete this step? screen. Click Yes.
Note: Normally, you wouldn't delete Blob Filter from your Job. But,
since we're simply counting pips on a die, you can delete it in this Job.
Click Blob Tool in the Step Tree to display the Blob Tool properties
11.
page.
Adjust the following Blob Tool properties:
12.
–
–
–
–
–
To display die1pip.tif, click
13.
FrontRunner™ displays the image and a box (the Blob Tool ROI), as
shown in Figure 2–3.
v4.1.0, February 2010
File List — Click <empty>, and then Add... to display the Open
dialog box. Browse for the file die1pip.tif from Windows. It's
located at:
C:\Vscape\Tutorials & Samples\Tutorials\HawkEye 1600T\Simple
Blob Tool
Select die1pip.tif and click Open.
Note: These files were installed from the installation CD onto your
hard drive when you installed Visionscape. If you installed
Visionscape to a location other than C:\vscape, replace it with the
appropriate drive and directory designation.
Use Autothreshold — Uncheck it.
High Threshold — Set to 64.
Maximum Blob size — Set to 10000.
Min Number of Blobs — Set to 1.
Max Number of Blobs — Set to 6.
