Microscan VS-1 Getting Started page 59

Note: You will not see this screen if no login parameters are set.
Enter your username and password (the defaults are "hawkeye" and
4.
"vision").
Click OK.
5.
If the camera is running, stop it by clicking
6.
FrontRunner™ displays the Device State Changed dialog box.
Because we're creating a new Job, click No.
7.
Start creating a new Job by clicking Create New Program, and then
8.
Editor, as shown in Figure 3–2.
FIGURE 3–2.
1
The camera will change to Edit Mode (indicated by the pencil next to
the camera icon).
To display the Step Tree and Editor, click
9.
This allows you to view your Job as you create it.
Note: Maximize or minimize the Editor as needed to accomplish the
steps in this procedure.
Highlight Acquire in the Step Tree (left pane). FrontRunner™ displays
10.
the Acquire properties page.
v4.1.0, February 2010
Start Creating New Job
Getting Started with the VS-1 Smart Camera
Advanced Example Using Multiple Tools
.
.
3
2
3-3
