Simple Flaw Tool - Microscan VS-1 Getting Started

Chapter 2
The VS-1 Smart Camera in Action - Simple Examples

Simple Flaw Tool

FrontRunner™ Job:
Start > Visionscape > Visionscape Tutorials & Samples > Tutorials >
HawkEye 1600T > Simple Flaw Tool > tutorial_flaw.avp
The Flaw Tool detects the presence or absence of a feature. For example,
it can determine whether a package has any defects in appearance, such
as cracks or scratches. The input to the Flaw Tool is an image buffer on
which to process. The output of the step at runtime is the pass/fail status
of the inspection. An output containing the resulting sum or count is also
available.
This example determines the presence or absence of a paper clip.
Start FrontRunner™ by selecting Start > Visionscape > Visionscape
1.
FrontRunner. FrontRunner™ displays its main window.
Do either of the following:
2.
a.
b.
Take control by clicking
3.
Device dialog box.
Note: You will not see this screen if no login parameters are set.
Enter your username and password (the defaults are "hawkeye" and
4.
"vision").
Click OK.
5.
If the camera is running, stop it by clicking
6.
FrontRunner™ displays the Device State Changed dialog box.
Because we're creating a new Job, click No.
7.
2-12 Getting Started with the VS-1 Smart Camera
For a camera already added to FrontRunner™, simply click the
camera button.
For a camera that has not been added to FrontRunner™, click
FrontRunner™ displays the Select Device dialog box. Select a
camera and click OK.
. FrontRunner™ displays the Login to
.
v4.1.0, February 2010
