Microscan Vision HAWK GMV-6800-1016G Manual

Smart camera
Hide thumbs

Advertisement

Quick Links

Download this manual
Microscan GMV-6800-1016G
Vision HAWK Smart Camera
A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
• C r i t i c a l a n d e x p e d i t e d s e r v i c e s
• I n s t o c k / R e a d y - t o - s h i p
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
In Stock
Used and in Excellent Condition
Open Web Page
https://www.artisantg.com/65563-1
• We b u y y o u r e x c e s s , u n d e r u t i l i z e d , a n d i d l e e q u i p me n t
• F u l l - s e r v i c e , i n d e p e n d e n t r e p a i r c e n t e r

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vision HAWK GMV-6800-1016G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microscan Vision HAWK GMV-6800-1016G

Summary of Contents for Microscan Vision HAWK GMV-6800-1016G

  • Page 1 Microscan GMV-6800-1016G Vision HAWK Smart Camera In Stock Used and in Excellent Condition Open Web Page https://www.artisantg.com/65563-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 Vision HAWK Smart Camera Guide 84-016800-02 Rev J...
  • Page 3 All rights reserved. The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service Omron Microscan manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Omron Microscan.
  • Page 4 Use of controls, adjustments, or performance of procedures other than those specified herein may result in hazardous laser or LED light radiation exposure. There are no user-serviceable parts in the imager. Opening the imager voids the Omron Microscan Systems, Inc. warranty.
  • Page 5 The information provided in this certification notice is correct to the best of Omron Microscan’s knowledge at the date of publication. This notice is not to be considered a warranty or quality specification. Users are responsible for determining the applicability of any RoHS legislation or regulations based on their individual use of the product.
  • Page 6 Contents PREFACE Welcome vii Purpose of This Manual vi Manual Conventions vi CHAPTER 1 Introduction 1-1 Product Summary 1-2 Features and Benefits 1-2 Applications 1-3 Package Contents 1-3 Vision HAWK Smart Camera Models 1-4 Part Number Structure 1-5 CHAPTER 2 System Components 2-1 Hardware Components 2-1 Important Label Information 2-8...
  • Page 7 Contents CHAPTER 3 Optics and Lighting 3-1 Optics 3-2 Lens Substitution 3-3 Illumination 3-5 Vision HAWK Color 3-12 APPENDIX A Connector Pinouts A-1 Vision HAWK Smart Camera Connectors A-2 APPENDIX B Cable Specifications B-1 61-000160-03 Cable, Host, Ethernet, M12 8-pin Plug to RJ45, 1 m B-2 61-000162-01 Cable, Common, M12 12-pin Plug to M12 12-pin Socket, 1 m B-3 97-000012-01 Power Supply, M12 12-pin Socket, 1.3 m B-4 99-000020-02 Trigger, M12 4-pin Plug, NPN, Dark On, 2 m B-5...
  • Page 8 Preface Welcome PREFACE Purpose of This Manual This manual contains detailed information about how to configure and operate the Vision HAWK Smart Camera. Manual Conventions The following typographical conventions are used throughout this manual. • Items emphasizing important information are bolded. •...
  • Page 9 Introduction CHAPTER 1 Vision HAWK Smart Camera, C-Mount and Standard Models FIGURE 1–1. Vision HAWK Smart Camera Guide...
  • Page 10 Chapter Introduction Product Summary The Vision HAWK Smart Camera is a compact industrial smart camera that provides powerful machine vision capabilities with a small form factor and intuitive software interface. The Vision HAWK is designed for industrial environments where IP65/67 enclosure and rugged M12 connectivity are required.
  • Page 11 Vision HAWK Smart Camera — Your package contains one of the available models listed in Table 1–1 • Microscan Tools Drive — USB flash drive containing AutoVISION software • Required accessories such as a power supply or power cable Vision HAWK Smart Camera Guide...
  • Page 12 Chapter Introduction Vision HAWK Smart Camera Models Table 1–1 lists and describes the Vision HAWK Smart Camera models. Vision HAWK Smart Camera Models TABLE 1–1. Part Number Vision HAWK Smart Camera Model GMV-6800-1000G Vision HAWK, SXGA, AutoVISION, C-Mount GMV-6800-1002G Vision HAWK, SXGA, AutoVISION+Visionscape, C-Mount GMV-6800-1004G Vision HAWK, SXGA, AutoVISION+Verification/OCV, C-Mount GMV-6800-1006G Vision HAWK, SXGA, AutoVISION+Visionscape+Verification/OCV, C-Mount GMV-6800-1010G Vision HAWK, WVGA, AutoVISION, C-Mount...
  • Page 13 Part Number Structure Vision HAWK Smart Camera Models TABLE 1–1. Part Number Vision HAWK Smart Camera Model GMV-6800-1404G Vision HAWK, SXGA, Built-In Lighting, AutoVISION+Verification/OCV, 12° Lens GMV-6800-1406G Vision HAWK, SXGA, Built-In Lighting, AutoVISION+Visionscape+Verification/OCV, 12° Lens GMV-6800-1410G Vision HAWK, WVGA, Built-In Lighting, AutoVISION, 12° Lens GMV-6800-1412G Vision HAWK, WVGA, Built-In Lighting, AutoVISION+Visionscape, 12°...
  • Page 14 Chapter Introduction Vision HAWK Smart Camera Guide...
  • Page 15 System Components CHAPTER 2 This section contains information about system components as well as information to help you connect the Vision HAWK Smart Camera. Specific information describes connectors, adapters, cables, pinouts, and signals. Note: There are no user-serviceable parts inside. Hardware Components Table 2-1 lists Vision HAWK Smart Camera hardware components.
  • Page 16 Chapter System Components Vision HAWK Smart Camera Hardware Components (Continued) TABLE 2–1. Part Number Description 61-000165-02 Cordset, Host, Serial M12 12 pin Plug to DB9 Socket, 3M 61-000163-02 Cordset, Host, Ethernet, M12 8 pin Plug to RJ45, 3M 61-000160-02 Cordset, Host, Ethernet, M12 8 pin Plug to RJ45, 1M 61-000166-02 Cordset, M12 12 Pin Plug to Flying Leads, 3M 61-000167-02...
  • Page 17 99-000020-02 Photo Sensor, M12 4-pin Plug, NPN, Dark On, 2 m Documentation Microscan Tools Drive (Software, User Manuals, Quick Start Guides, Configuration Guides, links to 37-000010-01 other documents on Microscan website) Note: Additional hardware components are available in the Microscan Product Pricing Catalog.
  • Page 18 Chapter System Components Standard Vision HAWK Front Figure 2-1 shows the front of the Vision HAWK Smart Camera. Front FIGURE 2–1. Standard Vision HAWK Base Figure 2–2 shows the base of the Vision HAWK Smart Camera. Base FIGURE 2–2. Vision HAWK Smart Camera Guide...
  • Page 19 Hardware Components Standard Vision HAWK Side Figure 2-3 shows the side of the Vision HAWK Smart Camera. Side FIGURE 2–3. Standard Vision HAWK Back Figure 2-4 shows the back of the Vision HAWK Smart Camera. Back FIGURE 2–4. Vision HAWK Smart Camera Guide...
  • Page 20 Chapter System Components Vision HAWK C-Mount Front Figure 2-5 shows the front of the Vision HAWK C-Mount Smart Camera. Front FIGURE 2–5. Vision HAWK C-Mount Base Figure 2–6 shows the top of the Vision HAWK C-Mount Smart Camera. FIGURE 2–6. Vision HAWK Smart Camera Guide...
  • Page 21 Hardware Components Vision HAWK C-Mount Side Figure 2-7 shows the side of the Vision HAWK C-Mount Smart Camera. Side FIGURE 2–7. Vision HAWK C-Mount Back Figure 2-8 shows the back of the Vision HAWK C-Mount Smart Camera. Back FIGURE 2–8. Vision HAWK Smart Camera Guide...
  • Page 22 Each Vision HAWK Smart Camera has its own label, which contains important information about that camera. • P/N – The Microscan part number of your Vision HAWK Smart Camera. • S/N — The serial number of your Vision HAWK Smart Camera.
  • Page 23 Mounting and Wiring the Vision HAWK Smart Camera Mounting and Wiring the Vision HAWK Smart Camera Important: Pin 9 (Host RxD) must be tied to ground (Pin 7) when using a flying lead cable and the serial port is not being used. The camera may not boot to completion if RxD is not grounded.
  • Page 24 Chapter System Components Optoisolated Outputs The reader has optoisolated outputs that can transfer signals from the camera to peripherals. Outputs can be configured as either NPN or PNP, but NPN and PNP cannot be mixed in a system, because the output common is shared by all outputs.
  • Page 25 Mounting and Wiring the Vision HAWK Smart Camera NPN Output for External Load Vision HAWK Smart Camera Guide 2-11...
  • Page 26 Chapter System Components PNP Output for Host Input 2-12 Vision HAWK Smart Camera Guide...
  • Page 27 Mounting and Wiring the Vision HAWK Smart Camera PNP Output for External Load Vision HAWK Smart Camera Guide 2-13...
  • Page 28 Chapter System Components Optoisolated Inputs All discrete inputs are optoisolated. Inputs can be configured as either NPN or PNP, but NPN and PNP cannot be mixed in a system, because the input common is shared by all inputs. 2-14 Vision HAWK Smart Camera Guide...
  • Page 29 Mounting and Wiring the Vision HAWK Smart Camera Vision HAWK Smart Camera Guide 2-15...
  • Page 30 Chapter System Components Input/Output Wiring 2-16 Vision HAWK Smart Camera Guide...
  • Page 31 Ground and Shield Considerations Ground and Shield Considerations Proper grounding is necessary for operator safety, noise reduction, and the protection of equipment from voltage transients. Buildings, including any steelwork, all circuits, and all junction boxes must be grounded directly to an earth ground in compliance with local and national electrical codes.
  • Page 32 Chapter System Components Expected Power and Ground Connections for Proper Operation Grounding Notes: • Ensure that mounting bracket “Earth” is at the same potential as power source “Earth”. • Supply “Return” and “Earth” ground must be stable, low-impedance reference points. •...
  • Page 33 Power Requirements Power Requirements Refer to Table 2-3 when determining the power supply requirements for your camera. Camera Power Requirements TABLE 2–3. Component Vision HAWK Smart Camera, CCD, 5-28VDC, 200mV p-p max ripple, SXGA 170mA at 24VDC (typ.) 15.5 watts (max.) Vision HAWK Smart Camera, CMOS, 5-28VDC, 200mV p-p max ripple, SXGA...
  • Page 34 Chapter System Components Status Indicators The top of the Vision HAWK Smart Camera has multiple LEDs that indicate different trigger, inspection, camera, communication, and power states. TRIG = Trigger Status PASS/FAIL = Inspection Status Outputs 1, 2, 3 MODE = Camera Status Power Status LINK/ACT = Link Activity Status On Steady...
  • Page 35 AutoVISION Button AutoVISION Button The AutoVISION Button has three positions, selectable by the length of time the button is held down, and indicated by one, two, or three beeps and LED flashes in succession. It can also be used to send a trigger signal when Send Trigger is checked in AutoVISION software’s Connect view.
  • Page 36 Power Supply, M12 12-pin Socket, 1.3 m 97-000012-01 Cordset, Host, Ethernet, M12 8-pin Plug to RJ45, 1 m 61-000160-03 Trigger, M12 4-pin Plug, NPN, Dark On, 2 m 99-000020-02 Note: Additional cables available in the Microscan Product Pricing Catalog. 2-22 Vision HAWK Smart Camera Guide...
  • Page 37 Setting Up a Job in AutoVISION – Mount the camera as required by the application. – Connect the Ethernet cable from "B" on the camera to the network. – Connect the power supply to "3" on the QX-1. – Connect the photo sensor to "T" on the QX-1. –...
  • Page 38 Chapter System Components Click the lock icon to take control of the camera. When you have control of the camera, the Modify button will appear beneath the camera settings. Click the Modify button to adjust camera settings. Note: The default IP address of the camera is: 192.168.0.10. Be sure your PC is on the same subnet (192.168.0.100, for example).
  • Page 39 Setting Up a Job in AutoVISION Once you have selected your camera, adjusted its settings, and created a new job, you will move to the Image view. This view allows you to Auto Calibrate the camera, and to manually adjust the camera's Exposure, Gain, and Focus, and also to set the Lighting Mode (On, Off, or Strobe).
  • Page 40 Chapter System Components Run the Job in AutoVISION. Going to the Run view will automatically download your job to the camera and start it running. Save the Job. Click the Save to Camera icon on the File menu bar to save the job to the Vision HAWK.
  • Page 41 Trigger overruns (when the vision system is triggered faster than the device can process) can be avoided by increasing the “debounce” time in the camera definition file located in the C:\Microscan\Vscape\Drivers\CamDefs directory. The IO Line Debounce High Time and IO Line Debounce Low Time can be added to the file as in the example below.
  • Page 42 Chapter System Components Gain Max // 0 to 100% Exp Dflt Exp Min Exp Max 100000 // 1/10 to 1/40,000 Focus Dflt Focus Min Focus Max 4000 // 1 to 40 inches // Lens Configuration C-Mount // 0 = false, 1 = true 2-28 Vision HAWK Smart Camera Guide...
  • Page 43 Optics and Lighting CHAPTER 3 This section describes the optical and illumination characteristics of the Vision HAWK Smart Camera. Vision HAWK Smart Camera Guide...
  • Page 44 Chapter Optics and Lighting Optics Image P/N / Model Sensor Shutter Focal Range Acquisition GMV-6800-1000G GMV-6800-1002G 1/3”, SXGA (1280 x 960) CCD, 6µs to 100ms (1/150,000 to 1/10) up to 20 FPS, Mono Default = 666µs (1/1,500) GMV-6800-1004G GMV-6800-1006G GMV-6800-1010G GMV-6800-1012G 1/3”, WVGA (752 x 480) CMOS, 25µs to 100ms (1/40,000 to 1/10)
  • Page 45 Lens Substitution Lens Substitution The following procedure will change the appropriate settings in the Vision HAWK to allow the camera to focus properly after the lens has been changed. Please note that the Vision HAWK camera will use default lookup tables for the focus when the lens selection is changed, so the actual focus distances may not be as accurate as the lens that was shipped with the unit that was factory calibrated.
  • Page 46 Chapter Optics and Lighting SetCurrentLens(4) (to change to 12° lens) The response should be: "Now Set to 4 = 12deg" "value = 0 = 0x0" Return Values: int – True if successful Send the following command to set focus limits: SetFocusLimits (min., max.) Min.
  • Page 47 Illumination Illumination The standard version of the Vision HAWK Smart Camera has built-in lighting. The LEDs can be configured to operate in multiple modes – Continuous, Strobe, and Off. Warning: Running a red LED board on a camera with a white or blue LED color profile will damage both the board and the camera.
  • Page 48 Proper lighting is critical to the success of a machine vision application. Depending on the requirements of your application, you may also need to add external lighting from Microscan’s NERLITE family of machine vision lighting products. Consider the following when setting up your application: –...
  • Page 49 Illumination External Illumination Control and Wiring The Vision HAWK C-Mount Smart Camera supports external lighting with Microscan’s NERLITE Smart Series lights. The diagram below demonstrates how the camera and light can be configured with the QX-1 interface device. The light is controlled using the Lighting control in the Camera configuration settings of AutoVISION software.
  • Page 50 Chapter Optics and Lighting Wiring for Strobe Illumination (NPN) In Strobe mode, the external illuminator is strobed with the exposure of the camera to maximize light for the short exposure times needed in dynamic applications. Warning: Contact between Pin 5 (gray wire) and any ground or voltage source less than or equal to 3.5VDC may cause erratic operation in this configuration.
  • Page 51 Illumination Wiring for Strobe Illumination (PNP) In Strobe mode, the external illuminator is strobed with the exposure of the camera to maximize light for the short exposure times needed in dynamic applications. Warning: Contact between Pin 5 (gray wire) and any ground or voltage source less than or equal to 3.5VDC may cause erratic operation in this configuration.
  • Page 52 Chapter Optics and Lighting Wiring for ON/OFF Illumination (NPN Only) ON/OFF allows the external illuminator to be enabled and disabled using the Vision HAWK’s I/O. Warning: Contact between Pin 5 (gray wire) and any voltage source greater than 3.5VDC will damage the illuminator. Smart Series Illuminator Vision HAWK Connector...
  • Page 53 Illumination Wiring for Continuous Illumination Warning: Contact between Pin 5 (gray wire) and any ground or voltage source less than or equal to 3.5VDC may cause erratic operation in this configuration. Contact between Pin 5 (gray wire) and any voltage source greater than 3.5VDC will damage the illuminator. Smart Series Illuminator Vision HAWK Connector...
  • Page 54 Chapter Optics and Lighting Vision HAWK Color This section describes Vision HAWK Smart Camera color functionality, which is available for the following models: • GMV-6800-1022G Vision HAWK, SXGA, Color, AV+VS, C-Mount • GMV-6800-1222G Vision HAWK, SXGA, Color, AV+VS, 30° Lens •...
  • Page 55 Vision HAWK Color FrontRunner Support for the Vision HAWK Color This section outlines the white balance support provided by FrontRunner for the Vision HAWK Color. White Balance Gain Values The color channel gain values can be viewed by clicking the Snapshot step, selecting the Acquire tab and then activating the Advanced parameters as shown below: The parameters are...
  • Page 56 Chapter Optics and Lighting White Balance Calibration Before running white balance calibration, place a white object such as a piece of paper in front of the camera at the current focus plane. Then initiate the white balance operation by selecting the white balance icon shown below.
  • Page 57 Vision HAWK Color Color Channel Options When a step is inserted in FrontRunner, the Color Channel or Interpolation operation can be selected or applied to the step as shown below: Use Fixed White Balance The color channel gain values can be fixed by clicking the Snapshot step, selecting the Acquire tab and then activating the Advanced parameters.
  • Page 58 Chapter Optics and Lighting Device parameters are referred to as camera parameters that are saved outside of a job, such that they can be applied globally or independent of a job as well as updated outside a job. These parameters include photometry settings (gain and exposure), focus, and white balance gain.
  • Page 59 Vision HAWK Color • Whenever an “unlocked” device parameter is updated, two things happen: – The device global data in RAM is updated; – The job loaded in RAM is updated. • When a job is saved to a job slot, the device global data file in the /Config flash folder is updated.
  • Page 60 Chapter Optics and Lighting White Balance Implementation White balance is a processing operation performed to ensure proper color fidelity in a captured digital image. The image sensor does not detect light exactly as the human eye does, and so some processing or correction of the detected image is necessary to ensure that the final image realistically represents the colors of the original image.
  • Page 61 Connector Pinouts APPENDIX A This section contains information about Vision HAWK Smart Camera connectors: • M12 12-Pin Plug on page A-2 • M12 8-Pin Socket on page A-3 Vision HAWK Smart Camera Guide...
  • Page 62 Appendix Connector Pinouts Vision HAWK Smart Camera Connectors Connector A – M12 12-Pin Plug – Power, I/O, and Serial Figure A–1 shows the M12 12-pin plug at connector A. Connector A – M12 12-Pin Plug FIGURE A–1. Table A–1 describes the M12 12-pin plug signals. Connector A –...
  • Page 63 Vision HAWK Smart Camera Connectors Connector B – M12 8-Pin Socket – Ethernet Figure A-2 shows the M12 8-pin socket at connector B. Connector B – M12 8-Pin Socket FIGURE A–2. Table A-2 describes the M12 8-pin socket signals. Connector B – M12 8-Pin Socket TABLE A–2.
  • Page 64 Appendix Connector Pinouts Vision HAWK Smart Camera Guide...
  • Page 65 Cable Specifications APPENDIX B This section contains information about Vision HAWK Smart Camera cables. Note: Cable specifications are published for information only. Microscan does not guarantee the performance or quality of cables provided by other suppliers. Cable Part Numbers and Descriptions TABLE B–1.
  • Page 66 Appendix Cable Specifications 61-000160-03 Cable, Host, Ethernet, M12 8-pin Plug to RJ45, 1 m The 61-000160-03 Cable, Host, Ethernet, M12 8-pin Plug to RJ45, 1 m is a 1 meter cable with an 8-pin M12 connector on one end and a standard RJ45 connector on the other end.
  • Page 67 61-000162-01 Cable, Common, M12 12-pin Plug to M12 12-pin Socket, 1 m 61-000162-01 Cable, Common, M12 12-pin Plug to M12 12-pin Socket, 1 m The 61-000162-01 Cable, Common, M12 12-pin Plug to M12 12-pin Socket, 1 m is a 1 meter cable with a 12-pin M12 plug on one end and a 12-pin M12 socket on the other end.
  • Page 68 Appendix Cable Specifications 97-000012-01 Power Supply, M12 12-pin Socket, 1.3 m The 97-000012-01 Power Supply, M12 12-pin Socket, 1.3 m is a 90-254 VAC, +24VDC power supply. Figure B-3 shows the 97-000012-01 Power Supply, M12 12-pin Socket, 1.3 m. Power Supply, M12 12-pin Socket, 1.3 m FIGURE B–3.
  • Page 69 99-000020-02 Trigger, M12 4-pin Plug, NPN, Dark On, 2 m 99-000020-02 Trigger, M12 4-pin Plug, NPN, Dark On, 2 m The 99-000020-02 Trigger, M12 4-pin Plug, NPN, Dark On, 2 m is a photo sensor with a 4-pin M12 connector. Figure B-4 shows the 99-000020-02 Trigger, M12 4-pin Plug, NPN, Dark On, 2 m.
  • Page 70 Appendix Cable Specifications Vision HAWK Smart Camera Guide...
  • Page 71 General Specifications APPENDIX C This section contains specifications and dimensions for the Vision HAWK Smart Camera and Vision HAWK C-Mount Smart Camera. Vision HAWK Smart Camera Guide...
  • Page 72 Appendix General Specifications Vision HAWK Smart Camera General Specifications Physical Characteristics P/N / Model Lens Type Dimensions Weight Connector GMV-6800-1000G GMV-6800-1002G GMV-6800-1004G GMV-6800-1006G GMV-6800-1010G GMV-6800-1012G 4.03” (102.3 mm) x GMV-6800-1014G C-Mount Lens 2.27” (57.6 mm) x 11 oz. (320 g) 1.59”...
  • Page 73 Vision HAWK Smart Camera General Specifications Optics Image P/N / Model Sensor Shutter Focal Range Acquisition GMV-6800-1000G GMV-6800-1002G 1/3”, SXGA (1280 x 960) CCD, 6µs to 100ms (1/150,000 to 1/10) up to 20 FPS, Mono Default = 666µs (1/1,500) GMV-6800-1004G GMV-6800-1006G GMV-6800-1010G GMV-6800-1012G...
  • Page 74 Appendix General Specifications Communications, I/O, Illumination, Laser Output P/N / Model Comm. Discrete I/O Indicators Illumination LED / Laser Output GMV-6800-1000G GMV-6800-1002G GMV-6800-1004G GMV-6800-1006G GMV-6800-1010G GMV-6800-1012G LEDs: Trigger, Pass, External Illumination GMV-6800-1014G Fail, Mode, Power, Required Network Activity, I/O GMV-6800-1016G GMV-6800-1022G GMV-6800-1030G GMV-6800-1032G...
  • Page 75 Vision HAWK Smart Camera General Specifications Power P/N / Model Power GMV-6800-1000G GMV-6800-1002G 5-28VDC, 200mV p-p max ripple, 170mA at 24VDC (typ.) GMV-6800-1004G GMV-6800-1006G GMV-6800-1010G GMV-6800-1012G 5-28VDC, 200mV p-p max ripple, 135mA at 24VDC (typ.) GMV-6800-1014G GMV-6800-1016G GMV-6800-1022G 5-28VDC, 200mV p-p max ripple, 170mA at 24VDC (typ.) GMV-6800-1030G GMV-6800-1032G 5-28VDC, 200mV p-p max ripple, 140mA at 24VDC (typ.)
  • Page 76 Appendix General Specifications Operating Environment; Agency Compliance Operating Storage P/N / Model Humidity Agency Compliance Temperature Temperature GMV-6800-1000G GMV-6800-1002G 0° to 45° C (32° to 113° F) GMV-6800-1004G GMV-6800-1006G GMV-6800-1010G GMV-6800-1012G 0° to 50° C (32° to 122° F) GMV-6800-1014G GMV-6800-1016G 0°...
  • Page 77 Dimensions Dimensions Vision HAWK Smart Camera Dimensions FIGURE C–1.  Note: Nominal dimensions shown. Typical tolerances apply. Vision HAWK Smart Camera Guide...
  • Page 78 Appendix General Specifications Vision HAWK C-Mount Smart Camera Dimensions FIGURE C–2. Note: C-Mount lens protection housing has a thread of M48 x 1.5. Note: Nominal dimensions shown. Typical tolerances apply. Vision HAWK Smart Camera Guide...
  • Page 79 Field of View and Working Distance Field of View and Working Distance Vision HAWK Smart Camera Guide...
  • Page 80 Appendix General Specifications C-10 Vision HAWK Smart Camera Guide...
  • Page 81 APPENDIX D CloudLink allows you to visualize Microscan Link values and images from compatible Microscan smart cameras and vision systems. It runs in your web browser, and is compatible with a wide variety of modern browsers including those found on tablets and smart phones.
  • Page 82 Connecting To launch CloudLink, use your favorite web browser and enter the address of your device in the browser’s address bar. For example, if you have a Microscan smart camera on your network at address 10.20.1.123, you would enter: CloudLink also works with Visionscape Software and with AutoVISION’s Emulator.
  • Page 83 Application Overview Application Overview The CloudLink Dashboard user interface is a single page web app-style application. Most web pages show information that can typically extend beyond the bottom of the browser window, requiring the user to scroll to see it. They typically contain links to other pages, which is how the user navigates around a web site.
  • Page 84 Appendix CloudLink Web HMI Application Bar The Application Bar is located at the top of the CloudLink interface. There are three components to the Appplication Bar: • A set of page selection buttons. In the example above they appear as tabs, but the style can be customized if necessary.
  • Page 85 The purpose of the panels is to act as containers for a number of widgets. Each widget has the ability to visualize and interact with one or more items of inspection data such as Microscan Link values, inspection counters, timing information, or images. Vision HAWK Smart Camera Guide...
  • Page 86 Appendix CloudLink Web HMI Each panel has special layout and behavior properties that can be exploited to create a wide variety of different layouts. The following table summarizes the position and properties of each panel: Vision HAWK Smart Camera Guide...
  • Page 87 Pages, Panels, and Widgets If a panel does not have content (i.e. no widgets are placed in it), it is hidden from view, with the other panels adjusted to occupy the available space. Examples of possible page layouts: Vision HAWK Smart Camera Guide...
  • Page 88 Appendix CloudLink Web HMI Vision HAWK Smart Camera Guide...
  • Page 89 Serial Commands APPENDIX E This section provides descriptions of the serial commands that can be sent to the camera via TCP (Telnet) port, AutoVISION Terminal, or HyperTerminal. Vision HAWK Smart Camera Guide...
  • Page 90 Appendix Serial Commands Serial Command Syntax < > = Required argument. Replace appropriately. For example: -u <DB_User_name> becomes -u av where av replaces DB_User_name. | = Mutually exclusive arguments. Choose one from the list. { } = Used with | to specify a list of choices for an argument. [ ] = Optional parameter.
  • Page 91 TRIGGER Triggers an inspection. vt [n] Triggers an inspection by pulsing a Virtual I/O point. For example: vt 1 will return pulse VIO1. The inspection will run if it is configured to use VIO 1 as a trigger. If specified, the VIO index must be in the allowed range for Virtual I/O points within Visionscape.
  • Page 92 Appendix Serial Commands JOBINFO [[-slot=]n] [-v] Gets job summary or info about slot n. JOBINFO with no arguments returns a list of all jobs on the device. -v = Verbose n. This option shows the amount of space that would be freed if the job were deleted.
  • Page 93 The value can be a list of comma-separated items to set a sequence of tags: Send SET int1 1, 2, 3 to set int1 = 1, int2 = 2, int3 = 3. The AVP service allows setting of step and datum information from the job tree using forward slash ‘/’...
  • Page 94 Appendix Serial Commands INFO [tagname|service] Gets information about a tag or service. INFO with no arguments gets a list of services. INFO <service> gets a list of tags in that service. INFO <service.tagname> gets attributes of the tag as well as a list of subtags. The AVP service allows retrieval of step and datum information from the job tree using forward slash ‘/’...
  • Page 95 Vision HAWK Boot Modes APPENDIX F This section describes the Vision HAWK’s Diagnostic Boot Mode and Boot Error Mode. Vision HAWK Smart Camera Guide...
  • Page 96 Appendix Vision HAWK Boot Modes Diagnostic Boot Mode The Vision HAWK supports a special boot mode used for diagnostics and recovery. There are two ways in which the camera can be put into this mode: This method requires an Ethernet connection between the host PC and Vision HAWK.
  • Page 97 Should your device need to be configured with different IP information, follow the example below and substitute the appropriate settings for IP address, subnet mask, and gateway address, respectively. [SAFE-KERNEL] BP_UpdateIP(“192.168.0.10”, “255.255.255.0”, “192.168.0.100”) It is possible to configure the system to acquire its IP address via DHCP or to use a static IP address.
  • Page 98 Appendix Vision HAWK Boot Modes Vision HAWK Smart Camera Guide...
