Microscan VS-1 Getting Started page 35

Note: You may have to click the Acquire tab in the properties window.
Adjust the following Acquire properties:
11.
–
–
Highlight Snapshot in the Step Tree (left pane). Right click Snapshot
12.
and click Insert Into. FrontRunner™ displays the Insert Step window.
Click on the Analysis Tools tab. Double click on Fast Edge Tool to
insert it into the Snapshot.
Highlight Fast Edge in the Step Tree (left pane), right click, and then
13.
click Rename. Rename it to Top Fast Edge.
In the Setup window, to view Chip01.tif, click
14.
displays Chip01.tif, as shown in Figure 2–19.
v4.1.0, February 2010
Picture Mode — Set to Load Images from File.
File List — Click <empty>, and then Add... to display the Open
dialog box. Browse for the file Chip01.tif from Windows. It is
located at:
C:\Vscape\Tutorials & Samples\Tutorials\HawkEye 1600T\Simple
Fast Edge Tool
Select Chip01.tif. Click Open.
Note: This file was installed from the installation CD onto your
hard drive when you installed Visionscape. If you installed
Visionscape to a location other than C:\vscape, replace it with the
appropriate drive and directory designation.
Getting Started with the VS-1 Smart Camera
Simple Fast Edge Tool
. FrontRunner™
2-21
