The VS-1 Smart Camera in Action - Simple Examples
Adjust the following Acquire properties:
11.
–
–
In the Setup window, to view DMs.tif, click
12.
displays DMs.tif, as shown in Figure 2–41.
FIGURE 2–41.
Highlight Snapshot in the Step Tree (left pane). Right click Snapshot
13.
and click Insert Into. FrontRunner™ displays the Insert Step window.
2-38 Getting Started with the VS-1 Smart Camera
Picture Mode — Set to Load Images from File.
File List — Click <empty>, and then Add... to display the Open
dialog box. Browse for the file DMs.tif from Windows. It is located
at:
C:\Vscape\Tutorials & Samples\Tutorials\HawkEye 1600T\Simple
Data Matrix Tool
Select DMs.tif. Click Open.
Note: This file was installed from the installation CD onto your
hard drive when you installed Visionscape. If you installed
Visionscape to a location other than C:\vscape, replace it with the
appropriate drive and directory designation.
DMs.tif
. FrontRunner™
