Chapter 3
The VS-1 Smart Camera in Action - Advanced Example
FIGURE 3–3.
Note: You may have to click the Acquire tab in the properties window.
Adjust the following Acquire properties:
11.
–
–
Highlight Snapshot in the Step Tree (left pane). Right click Snapshot
12.
and click Insert Into. FrontRunner™ displays the Insert Step window.
Click on the Analysis Tools tab. Double click on Fast Edge to insert it
into the Snapshot.
In the Setup window, to view opto01.tif, click
13.
FrontRunner™ displays Opto01.tif, as shown in Figure 3–4.
14.
3-4 Getting Started with the VS-1 Smart Camera
Acquire Step
Picture Mode — Set to Load Images from File.
File List — Click <empty>, and then Add... to display the Open
dialog box. Browse for the files opto01.tif and opto02.tif from
Windows. They are located at:
C:\Vscape\Tutorials & Samples\Tutorials\HawkEye
1600T\Advanced Example Using Multiple Tools
Select opto01.tif and opto02.tif. Click Open.
Note: These files were installed from the installation CD onto your
hard drive when you installed Visionscape
®
Visionscape to a location other than C:\vscape, replace it with
the appropriate drive and directory designation.
®
. If you installed
.
