Creating A New Job To Acquire Images - Microscan VS-1 Getting Started

Note: The green triangle symbol indicates that the camera is currently
running a job.
From this point on, you can simply click on the device button for your
11.
camera to establish a connection.

Creating a New Job to Acquire Images

The instructions that the VS-1 Smart Camera performs in a particular
application are called "Steps", and the complete collection of steps is
called a "Job". To do anything, even to take a picture, the VS-1 Smart
Camera requires a Job. Use the following procedure to create a new Job:
Click the device button for your camera.
1.
Take control of the camera by clicking
2.
This will display the Login to Device dialog box, where you should
enter the username (hawkeye) and password ("vision") and then click
OK.
To begin creating a new Job, select File > New Job (or click
3.
FrontRunner™ displays the screen shown in Figure 1–6.
v4.1.0, February 2010 Getting Started with the VS-1 Smart Camera
Creating a New Job to Acquire Images
.
1
).
1-5
