Chapter
3
The VS-1 Smart Camera in Action - Advanced Example
b.
c.
Adjust the three Fast Edge tools so that they look like the image in
18.
Figure 3–5.
FIGURE 3–5.
Highlight Left Fast Edge in the Step Tree (left pane).
19.
Adjust the following Left Fast Edge properties:
20.
–
–
3-6
Getting Started with the VS-1 Smart Camera
Highlight the second Fast Edge in the Step Tree (left pane), right
click, and then click Rename. Rename the second Fast Edge to
Top Fast Edge.
Highlight the third Fast Edge in the Step Tree (left pane), right
click, and then click Rename. Rename the third Fast Edge to
Right Fast Edge.
Opto with Three Fast Edges Adjusted
Scan Direction — Set to Left to Right
Transition color — Set to Dark to Light
v4.1.0, February 2010
