Chapter 1
Using a VS-1 Smart Camera for the First Time
FIGURE 1–6.
To acquire a new image, click
4.
in the display area.
To display a "live" image, click
5.
To bring up the step editing environment, click
6.
You will see a hierarchy of steps on the left hand side of the editor, as
shown in Figure 1–7.
1-6 Getting Started with the VS-1 Smart Camera
FrontRunner Main Screen After Clicking New Job
Acquire New Image
Live Video
. You should see an image appear
. (Click it again to exit live video.)
.
