Microscan VS-1 Getting Started page 51

Start creating a new Job by clicking Create New Program, and then
8.
Editor, as shown in Figure 2–39.
FIGURE 2–39.
1
The camera will change to Edit Mode (indicated by the pencil next to
the camera icon).
To display the Step Tree and Editor, click
9.
This allows you to view your Job as you create it.
Note: Maximize or minimize the Editor as needed to accomplish the
steps in this procedure.
Highlight Acquire in the Step Tree (left pane). FrontRunner™ displays
10.
the Acquire properties page.
FIGURE 2–40.
Note: You may have to click the Acquire tab in the properties window.
v4.1.0, February 2010
Start Creating New Job
Acquire Step
Getting Started with the VS-1 Smart Camera
Simple Data Matrix Tool
2
.
2-37
2
