Simple Blob Tool

FrontRunner™ Job:
Start > Visionscape > Visionscape Tutorials & Samples > Tutorials >
HawkEye 1600T > Simple Blob Tool > tutorial_blob.avp
The Blob Tool performs connectivity analysis on an image, finding groups
of connected pixels with gray levels above or below a threshold. Each
group is called a blob. The Blob Tool records all the detected blobs into a
blob tree. For each blob, the tool calculates many geometric features
including the length, width, area, etc. In addition, the number of blobs and
number of parts in the region of interest (ROI) are calculated. A part is a
blob that has the opposite color of the background. A hole is a blob with
the same color as the background.
This example counts the number of pips on a die.
Start FrontRunner™ by selecting Start > Visionscape > Visionscape
1.
FrontRunner. FrontRunner™ displays its main window.
Do either of the following:
2.
a.
b.
Take control of the camera by clicking
3.
FrontRunner™ displays the Login to Device dialog box.
Note: You will not see this screen if no login parameters are set.
Enter your username (default is "hawkeye") and password (default is
4.
"vision"), and click OK.
If the camera is running, stop it by clicking
5.
displays the Device State Changed dialog box. Because we're
creating a new Job, click No.
