The optional handheld IR remote control allows channel preset recall and channel
navigation. The SMD 101 automatically detects transport and stream formats and decodes
the content for presentation to the display.
A channel list can be defined that allows simple selection of individual streams. The user can
import or export source selection data including URLs and associated data from the channel
list. This is an extension of the configuration save or restore capability that can save box and
IP configuration settings for the product as a separate file.
The channel list can be accessed with an optional remote control for selection and playing
streams included in the list.
The SMD 101 decodes all common stream resolutions and frame rates.
The SMD 101 can be configured using a host PC or laptop connected to the front
panel USB Config port, the RJ-45 LAN connector, or the RS-232 port (see
Communication and Control
connected to the same network as the SMD 101 can access the embedded HTML pages.
A video confidence display allows image monitoring from the user interface while making
configuration and control adjustments.

Video Output

Video output parameters are configured automatically for the connected display based
on the display EDID, or can be configured manually using a browser and the video
configuration page.
NOTE:
• The SMD 101 does frame rate conversion between the input stream frame rate and
the output frame rate, scaling from the source resolution and output resolution, and
aspect ratio between fit (zoom), fill, and follow as required.
• Fill and follow background, when necessary, is black.
By default, the SMD 101 automatically outputs video corresponding to EDID data from the
connected display within the resolution and rate combinations (see
EDID Support Table
capabilities. EDID data exchange is compatible with E-EDID V2.0 (EDID data structure 1.4)
and EIA/CEA-861E.
on page 111). A compatible web browser on a control PC
on page 5). The output rates available are limited by the display
Remote
Output Resolution and
SMD 101 • Introduction 3
