HTTP Connection to an SME 100
To connect SME 100 unicast or multicast push streams over HTTP, use the following
templates.
For unicast streams with no password, the URI format is:
http://<sme100_ip>/Web/output1.sdp
For multicast RTP over UDP RTSP (pull) streams with no credentials set, the URI format is:
http://<sme100_ip>/Web/multicast.sdp
NOTES:
• A typical IPv4 address for an SME 100 device on a private network is
192.168.nnn.nnn or 10.nnn.nnn.nnn).
•
A multicast address for a private network will typically be in the range 239.0.0.1
to 239.255.255.254 with some exceptions, the range may be subdivided by
larger organizations to match the geographical layout of sites.
If the encoder has an active admin password, it challenges the connection. An admin or
user password is required for connection. To play the stream, the user name and password
must be embedded in the URI entered in the Source field.
For unicast or multicast PUSH streams with a password, the URI format is:
http://user:password
For multicast RTP over UDP RTSP (pull) streams with a password, the URI format is:
http://user:password
In the following example, connect to a unicast RTSP over UDP stream broadcast from the
SME 100 in
1.
Locate the HTTP stream in the streams browser (see
page 22).
2. Drag and drop the stream into the player panel. An error message indicates the stream
load failed. The URI of the stream is shown in the Source: field.
3. Click the ellipsis (...) to open the full file path.
http:192.168.254.254/web/extron.sdp
http:192.168.254.254/web/extron.sdp
Figure 99.
4.
Add the SME 100 user name and password.
http://admin:123456@192.168.254.254/web/extron.sdp
http://admin:123456@192.168.254.254/web/extron.sdp
Figure 100.
5. Press <Enter> to load the stream.
The stream loads. If Load Play is active, the stream begins playing. If Load Play is not
active, press play (see
.
@
<sme100_ip_adr>/Web/output1.sdp
@
<sme100_ip_adr>/Web/output1/multicast.sdp
figure 98 on page 106, with the admin user account and password "123456".
Source Path Dialog
Source Path Dialog, Add User Name and Password
Player Controls Features
.
.
Player Page Overview
on page 23) to play the stream.
SMD 101 • Advanced Player Configuration
.
