The SMD 101 can decode and display one SD or HD stream. The optional handheld
IR remote control allows channel preset recall and channel navigation. The SMD 101
automatically detects transport and stream formats and decodes the content for
presentation to the display.
A channel list can be defined that allows simple selection of individual streams. The user can
import or export source selection data including URLs and associated data from the channel
list. This is an extension of the configuration save or restore capability that can save box and
IP configuration settings for the product as a separate xml file.
The channel list can be accessed with a remote control (not included) for selection and
playing streams included in the list.
The SMD 101 decodes all common stream resolutions and frame rates.
NOTES: The SMD 101 does not support decoding of encrypted content.
The SMD 101 can be configured using a host PC or laptop connected to the front
panel USB Config port, the RJ-45 LAN connector, or the RS-232 port (see
Communication and Control
connected to the same network as the SMD 101 can access the embedded HTML pages.
A video confidence display allows image monitoring from the user interface while making
configuration and control adjustments.

Video Output

Video output parameters are configured automatically for the connected display based
on the display EDID, or can be configured manually using a browser and the video
configuration page.
NOTE:
• The SMD 101 does frame rate conversion between the input stream frame rate
and the output frame rate, scaling from the source resolution and output resolution,
and aspect ratio between fit (zoom), fill, and follow as required.
• Fill and follow background, when necessary, is black.
The SMD 101 by default, automatically outputs video corresponding to EDID data from the
connected display within the resolution and rate combinations (see
EDID Support Table
capabilities. EDID data exchange is compatible with E-EDID V2.0 (EDID data structure 1.4)
and EIA/CEA-861E.
on page 57). A compatible web browser on a control PC
on page 4). The output rates available are limited by the display
Remote
Output Resolution and
SMD 101 • Introduction 3
