- Page 1 User’s Guide HDSDI-ACR 100 SDI-AVR 100 High Definition SDI to Component Video/RGB Converter SDI to Video/RGB Converter 68-553-01 C Printed in the USA 02 02...
-
Page 2: Installation Overview
The input signal is equalized for distances of 330 feet (100 meters) Figure 3 shows the HDSDI-ACR 100 connections and DIP switches. (HDSDI-ACR 100) or 1000 feet (305 meters) (SDI-AVR 100) on high Figure 4 shows the SDI-AVR 100. quality cable such as Extron SHR cable. A reclocked loop-through allows the HDSDI/SDI input to be sent to other equipment. -
Page 3: Installation
SOG switch — Set this switch to the On position to output sync- on-green for RGB video (RGsB). Set the switch off for LED (HDSDI-ACR 100 only) — The 720P LED indicates that RGBHV or RGBS video. the converter is outputting the HDTV 720P video format. -
Page 4: Specifications
Extron SHR cable or Belden 8281 cable. HDSDI-ACR 100 HDSDI TO VIDEO/RGB CONVERTER The equalization applied to the HDSDI-ACR 100’s input signal is sufficient for an input coaxial cable length of at least 330 feet (100 meters) of Extron SHR cable or Belden 8281 cable. - Page 5 Standards (SDI-AVR 100 only) .. NTSC 3.58, PAL 4.43, Betacam Output impedance ....... 75 ohms Max. rise/fall time ....... 200 nS Polarity .......... SDI-AVR 100 .... negative HDSDI-ACR 100 ..bi-level or tri-level sync (switch selectable) on luma (Y) leg General Power ..........
