Optimum Network Share Performance

For optimum performance, the PC used for network file sharing should be a dedicated
server. In smaller systems using a desktop PC, the computer must be configured for the
task. You may need to allocate additional resources on the PC by setting the following
registry key to 3:
HKLM\SYSTEM\CurrentControlSet\Services\LanmanServer\Parameters\Size.
Image quality and playback can be compromised when files are uploaded to the player
during active playback.

Network Shares Dialog

The SMD 202 network shared folder dialog provides options for flexibility within the
SMB/CIFS protocol (see
add a credentials file, change the port mapping, configure security related features, and
add security mode settings. Other options provide the ability to set the read/write mode,
filename character remapping, and control over filename case sensitivity. The options field is
not normally required. If the network connection fails, or you cannot access a server folder,
contact your network administrator to determine if these options are necessary for your
network.
NOTES:
Play Video from a Network Share
• The SMB version and domain (if required) must be set using the options field in the
network share dialog.
Recommended Example: vers=3.0,domain=USERDOMAIN,echo_interval=10
• No spaces are permitted in the options field. The version number must be one
of those listed above. The domain is required when the user account is a local
account on the server as opposed to a corporate domain account.
on page 103). You can
SMD 101 • Reference Information 139
