Accessing the Embedded Web Pages

After the SMD 101 and the encoders and codecs that will serve as stream sources are
installed, open the web pages that are embedded within the internal memory.
To open the SMD 101 embedded web pages:
1.
2.
3.
4.
The SMD 101 embedded web page opens to the Player page (see
Features

Overview of the SMD 101 Embedded Web Pages

The SMD 101 embedded web pages provide the software user interface for operating and
configuring the streaming media decoder via a control PC on the same network.
All SMD 101 web pages include the Player Controls tab at the left of the screen (see
Player Controls Features
for operating the SMD 101.
The pages provide the following features:
•
•
•
•
Open a web browser.
Enter the IP address of the SMD 101 (if the IP address has not been changed, the
default IP address is 192.168.254.254) into the browser address bar (see figure 10).
Figure 10. Enter the IP Address
NOTE: If you are not able to connect to the SMD 101, the IP address may have
been changed. See the
instructions on returning it to the default IP address without disturbing the
configuration.
The embedded web pages open to the Player page (see
page 28).
If necessary, enter the user name and password (see
page 19).
Click Log In or OK.
on page 23).
on page 23). The Player page serves as the main interface
Fully configure the SMD 101 from a remote location
Remote control and active monitoring of the SMD 101
A full color embedded video confidence window
Update firmware
Front Panel Configuration Port
Logging Out and Logging In
SMD 101 • Web-based User Interface
on page 112 for
Player Page Layout on
on
Player Controls
16
