Extron electronics II Specification Sheet

S
UPER
S
UPER
24-HOUR
H
SUPPORT
IGH
S
UPER

APPLICATION

™
Super Emotia II
Extron's Super Emotia II is a high resolution,
real-time scan converter that converts VGA,
SuperVGA, XGA, SGI and M /Quadra computer
AC
signals to standard NTSC or PAL video. The Super Emotia II is multiscanning, allowing it to
automatically recognize and convert all incoming resolutions up to 1024 x 768 (up to 50 kHz
interlaced and non-interlaced), into a composite video, S-Video and RGBS output.
The Super Emotia II is an affordable, professional quality scan converter with high performance
features. Using new digital technology, the Super Emotia II provides exceptional video output
quality with minimal loss of signal integrity. The Super Emotia II includes a built-in anti-flicker
filter that helps eliminate unwanted single pixel line flicker associated with scan conversion.
Super Emotia™ II GX
The Super Emotia II GX is functionally the same as the Super Emotia II, but provides genlock
capability and component video output.

FEATURES

Super Emotia II
• Multiscans up to 1024 x 768
(up to 50kHz)
• Professional quality video output
• 16 memory settings that store size
and position settings
• 200% zoom with pan capability
• Freeze frame
• Horizontal/vertical sizing & positioning
• NTSC/PAL and S-VHS (S-Video) outputs
• Overscan/underscan switch
• Anti-flicker reductions switch to reduce
traces of flicker
• Metal enclosure

INCLUDED ACCESSORIES

VGA input cable, 6' (1.8 m)
S-Video cable, 6' (1.8 m)
M /VGA adapter
AC
RCA cable, 6' (1.8 m)
15-8
Extron Electronics TECHNICAL SUPPORT 800.633.9876
Extron Electronics, Europe
E ™ II & S
MOTIA
VGA, XGA, SGI
R M
ESOLUTION AC
E II GX
MOTIA
Super Emotia II GX
• Genlock
• Professional component video output
• Professional quality video output
• Multiscans
• Memory settings
• Pan and zoom capability
• Freeze frame
• Horizontal/vertical sizing
& positioning
• Overscan/underscan switch
• Anti-flicker
• Metal enclosure
• BNC's with horizontal and
subcarrier phase adjustments
M /VGA return cable, 1' (.30 m)
AC
M HV/VGA return cable, 1' (.30 m)
AC
BNC/M-RCA/F adapter
+31.33.453.4040 FAX +31.33.453.4050
PRICES AND SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
UPER
AND
S C
CAN ONVERTERS

SPECIFICATIONS

Video
Computer input
Connector ............................... VGA - 15 pin HD, male
Resolution ............................... Multiscanning up to 1024 x
Frequency
Horizontal........................... Up to 50 kHz
Vertical ............................... Up to 130 kHz
Video output
NTSC/PAL ......................... Single female BNC (with
S-VHS................................. 4-pin din (S-Video) female
RGBS .................................. 4-BNC female (chassis
Component ......................... Super Emotia II GX only;
General
S E II
UPER MOTIA
Power supply ........................... 100-240 VAC, 50/60 Hz;
Approvals ................................. CE, UL, CUL listed
Dimensions ............................. 1.5"H x 10"W x 11.5"D
Temperature
Storage ................................ –40 C to +70 C,
Operating ............................ 0 C to 50 C
Humidity ................................. 10% to 90%
Vibration ................................. NSTA 1A in carton
Shipping weight ...................... 8 lbs. (3.6 kg)
Warranty ................................. Two years, parts & labor
Enclosure ................................ Metal

PART NUMBERS

Super Emotia II
Super Emotia II GX
Super Emotia II GX
M O
-Z
HI
O UT
U
CP
75
T
IN PU
ER
W T
PO PU
IN
Rear
714.491.1500 FAX 714.491.1517 FAXBACK 714.491.0192
Extron Electronics, Asia
E ™ II GX
MOTIA
768, interlaced/non-
interlaced
RCA adapter included)
mount)
female BNC
External switch mode
3.8 H x 25 W x 29 D cm
60-158-01
60-159-01
CK
LO IN
G EN
HI -Z
External
Y S
B/ B-
T
OU O UT
75
Y
R- G /Y
R/ Genlock
Y
B-
Y/
R- BS
RG
O Timing
DE TS
S- VI PU
O UT
O
DE
VI
R
TO
NI
RGBS
T
PU
S-Video
Composite Video
VGA/Mac
Adapter
Cable
Mac/VGA
Adapter
MAC/Quadra
PC VGA/SVGA
www.extron.com
+65.226.0015 FAX +65.226.0019
List price
$1695.00
$2595.00
Output Devices
Monitor
Teleconferencing
Equipment
Video Tape Player
