S
PECIFICATIONS

VIDEO INPUT

Number/signal type .............................. 1 (RGBHV, RGBS, RGsB)
Connectors ............................................ 1 BNC female
Minimum/maximum levels .................... Analog – 0.0V to 1.0V p-p
Impedance ............................................ 75 ohms
Horizontal frequency.............................. NTSC 3.58, NTSC 4.43, PAL,
Vertical frequency .................................. NTSC 3.58, NTSC 4.43, PAL,
Resolution range .................................... NTSC 3.58, NTSC 4.43, PAL,
Return loss ............................................ -30dB @ 5 MHz
Maximum DC offset .............................. 1.5V

VIDEO PROCESSING

Decoder ................................................ 9 bit digital
Digital sampling .................................... 24 bit, 8 bits per color;

VIDEO OUTPUT

Number/signal type .............................. 1 scaled or pass-through RGBHV,
Connectors .............................................. 6 female BNC 1 female 15-pin HD
Minimum/maximum levels .................... 0.0V to 0.7V p-p
Impedance ............................................ 75 ohms
Scaled VGA resolution ............................ 640x480
SYNC
Input type .............................................. RGBHV, RGBS, RGsB
Output type .......................................... RGBHV, RGBS, RGsB
Standards........................................................ NTSC 3.58, NTSC 4.43, PAL,
Input level.............................................. 0V to 1.0V p-p
Output level .......................................... TTL 5.0V p-p
Input impedance.................................... 75 ohms
pass-through, RGBcvS
1 composite video, S-video,
component video (Y, R-Y, B-Y)
1 S-video, 1 SDI (optional,
DVS 204 D only)
1 composite video
composite video
3 female BNC
composite, S-video,
component video
1 4-pin mini-DIN female
S-video
1 15-pin HD female
RGB pass-through
1 BNC female
SDI (DVS 204D only)
with no offset
SECAM
SECAM
SECAM
13.5 MHz standard
Colors: 16.78 million
RGBS, RGsB; or scaled
component video (Y, R-Y, B-Y)
1,3,4,5,6 800x600 1,3,4,5,6
848x480 1,3,4,5,6, 852x480 1,3,4,5,6
1024x768 1,3,4,5,6 1280x768 2,3,5,6
1280x1024 1,3,4,5
1360x765 1,3,4,5,6
1365x1024 1,3,4,5 HDTV 480p 3,5
720p 3,5 1080p 3,5 and 1080i 3,5
1 = at 50 Hz 2 = at 56 Hz
3 = at 60 Hz 4 = at 75 Hz
5 = locked to the current input's
vertical refresh rate
6 = True Rate
SECAM
Output impedance ................................ 75 ohms
Max input voltage.................................. 5V p-p
Max. propagation delay ........................ 20 nS
Polarity .................................................. Positive or negative
CONTROL/REMOTE — DECODER/SCALER
Serial control port .................................... RS-232, 9-pin female D connector
Baud rate and protocol .......................... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configurations ............ 1 = input 1 select
Contact closure...................................... 9-pin female D connector (same
Contact closure pin configurations ........ See pins 1, 4, 6, and 7 above.
IR controller module .............................. Extron IR 901 (optional)
Program control .................................... Extron's control program for
GENERAL
Power
DVS 204, DVS 204D .................. 100VAC to 240VAC, 50/60
DVS 204/204D 12VDC .............. 100VAC to 240VAC, 50/60
Rack mount............................................ Yes, with optional rack shelf,
Enclosure type........................................ Metal
Enclosure dimensions ............................ 1.75" H x 8.75" W x 9.5" D
Product weight ...................................... 3.3 lbs (1.5 kg)
Shipping weight .................................... 6 lbs (2.7 kg)
Vibration ................................................ ISTA/NSTA 1A in carton
Listings .................................................. UL, CUL
Compliances .......................................... CE, FCC Class A, VCCI, AS/NZS,
MTBF .................................................... 30,000 hours
Warranty ................................................ 3 years parts and labor
Model
DVS 204.......................................... 60-442-01
DVS 204 D ...................................... 60-442-02
DVS 204
(12V external power supply) ...... 60-442-11
DVS 204 D (with SDI input and
12V external power supply) .......... 60-442-12
(switch-selectable)
2 = TX, 3 = RX, 4 = input 2 select
5 = GND, 6 = input 3 select
7 = input 4 select, 8 = n/a,
9 = hardwired IR
as RS-232 connector)
Windows ® Extron's Simple
Instruction Set ™ – SIS ™
Hz, 30 watts, internal,
autoswitchable
Hz, 36 watts, external,
autoswitchable; to 12VDC,
3 A power supply.
Product requires 2 A.
part #60-190-01
(1U high, half rack width) 4.4 cm
H x 22.2 cm W x 24.1 cm D
(Depth excludes connectors and
knobs. Width excludes rack ears.)
(International Safe Transit
Association)
ICES
Part Number
