ASCII Command
Command
(host to unit)
HDCP Output Mode
E S X54^ HDCP }
Set HDCP mode
(single output)
Query HDCP mode E SHDCP }
(single output)
X54^ X54^ = HDCP output mode
KEY:
Test pattern
E X52@ TEST }
Select test pattern
E O 1PLYR }
Stop test pattern
NOTE: Instead of stopping the test pattern output, you can also select the input using the
E TEST }
View
X52@ X52@
KEY: = Test pattern
Audio
E O1AFMT }
Set dual mono
E O2AFMT }
Set stereo
E OAFMT }
View audio output
format
X55) V
Set volume
Increment volume +V
Decrement volume -V
V
View volume
1Z
Mute on
0Z
Mute off
Z
View audio mute
status
X51) X51)
KEY: = Enable or disable
X55) X55) = Audio volume
X55! X55!
= Analog audio format
Output CEC Mode
E O 1 * X# CCEC }
Set CEC mode for
single output
E O 1 CCEC }
Query CEC mode for
output
X# X#
KEY: = CEC Mode
Response
(unit to host)
HdcpS X54^ ]
X54^ ]
HdcpS X54^ ]
0=Follow input (max 10-secs of authentication trials[default])
1=Encrypt output (max 10-secs of authentication trials)
2=Follow input (continuous authentication trials)
3=Encrypt output (continuous authentication trials)
4=No authentication
X52@ ]
PlyrO1 ]
X52@ ]
See the test pattern selection table
AfmtO1 ]
AfmtO2 ]
X55! ]
Vol X55)]
Vol X55)]
Vol X55)]
X55) ]
Amt1 ]
Amt0 ]
X51)]
0=Mute off/disabled, 1=Mute on/enabled
0 to -100 dB in 1 dB steps, -30=default, -100=mute
1=Dual mono, 2=Stereo (default)
CcecO1* X# ]
X# ]
CcecO X# ]
0=Disable CEC operations for this IO port (default)
2=Enable insertion (and break CEC connection input to output [unidirectional])
SMD 101 • Remote Communication and Control
Additional Description
Set the HDCP mode to
Query the HDCP mode
(Verbose mode 2/3)
controls.
Playback
on page 118.
Set analog output volume to
X55)
.
Increase analog audio volume
by 1 dB.
Decrease analog audio volume
by 1 dB.
Enable or disable CEC
operation on output 1
Query CEC operating mode
Verbose mode 2/3
X54^
