Extron electronics SMD 101 User Manual

Extron electronics SMD 101 User Manual

H.264 streaming media decoder
Hide thumbs Also See for SMD 101:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Setup Manual
User Guide
Streaming AV Products
SMD 101
H.264 Streaming Media Decoder
68-2231-01 Rev. A
03 14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMD 101 and is the answer not in the manual?

Questions and answers

Related Manuals for Extron electronics SMD 101

Summary of Contents for Extron electronics SMD 101

  • Page 1 User Guide Streaming AV Products SMD 101 H.264 Streaming Media Decoder 68-2231-01 Rev. A 03 14...

  • Page 2: Safety Instructions

    Safety Instructions Инструкция по технике безопасности • Русский Safety Instructions • English ПРЕДУПРЕЖДЕНИЕ: Данный символ, , если указан WARNING: This symbol, , when used on the product, is intended to alert the user of the presence of uninsulated dangerous voltage within the на...
  • Page 3 FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 4 Conventions Used in this Guide Notifications The following notifications are used in this guide: CAUTION: A caution indicates a situation that may result in minor injury. ATTENTION: Attention indicates a situation that may damage or destroy the product or associated equipment. NOTE: A note draws attention to important information.

  • Page 5: Table Of Contents

    Contents Date and Time ..........40 Introduction ............ 1 Password ............. 40 About this Guide ..........1 Reset Device ..........42 About the SMD 101 ..........1 SNMP ............43 Video Output ..........3 Device Information Page ........44 Output Resolution and EDID Support Table ... 4 Status Page ............
  • Page 6 Reference Information ......... 81 Parts and Accessories ........81 Mounting the SMD 101 ........81 Tabletop Use ..........81 Rack Mounting ..........82 Furniture Mounting........82 Table or Wall Mounting ........82 SMD 101 Reset Summary ........ 83 Optimum Network Share Performance ..... 85 Network Shares Dialog .........

  • Page 7: Introduction

    Introduction This section gives an overview of the user guide and describes the SMD 101 and its features. Topics that are covered include: • About this Guide • About the SMD 101 Features • About this Guide This guide contains installation, configuration, and operating information for the SMD 101. In this guide: •...
  • Page 8 SME 100 SI 26 D IO Surface-mount Streaming Audio Speakers Encoder HDMI/RGB - - A Extron A 10 SMD 101 Sound System Streaming IT ER LI M SI GN Media Decoder Extron XPA 1002 Stereo Power Ampli er HD Display HDMI/RGB/Analog Figure 1.

  • Page 9: Video Output

    The SMD 101 can decode and display one SD or HD stream. The optional handheld IR remote control allows channel preset recall and channel navigation. The SMD 101 automatically detects transport and stream formats and decodes the content for presentation to the display. A channel list can be defined that allows simple selection of individual streams.

  • Page 10: Output Resolution And Edid Support Table

    Output Resolution and EDID Support Table Resolution 23.98 Hz 24 Hz 25 Hz 29.97 Hz 30 Hz 50 Hz 59.94 Hz 60 Hz 640x480 800x600 1024x768 1280x1024 1366x768 1600x1200 1920x1200 480p 576p 720p (default) 1080i 1080p NOTES: • Numbers indicate the EDID preset resolution. •...

  • Page 11: Suggested Pc Requirements

    Suggested PC Requirements The suggested PC requirements to access the default web pages of the SMD 101 are listed below. • Hardware 2.0 GHz dual-core processor • • Operating Systems Microsoft Windows XP or higher • ® ® 10.6 or higher ®...

  • Page 12: Features

    • Control from IR remote, wired IR, RS-232, Ethernet, or embedded web interface — Select from a range of control options to manage the SMD 101 for stand-alone operation or as part of an AV system. Compatible with the full range of SME 100 streaming transport protocols —...
  • Page 13 Playback controls including progress bar — On-screen playback controls present a • visual indication of Time and Pause status, allowing for efficient control of content. Compatible with many third party H.264 encoders — Decode 720p/60 and • 1080p/60 streaming video from an Extron SME 100 or other compatible H.264 encoders.

  • Page 14: Panels And Cabling

    Hardware Setup Overview • Front Panel Features The front panel of the SMD 101 is shown in figure 2 below. A A B B C C CONFIG SMD 101 Power LED IR receiver window Playback status indicator Config port Network status indicator Figure 2.

  • Page 15: Rear Panel Features

    IR Receiver Window— Allows remote operation using an optional compatible IR hand control. Config port — Connect a control PC or other USB device to this port using a mini-B USB cable (not supplied). Use this port to send Simple Instruction Set (SIS) commands to the SMD 101 for device configuration and control.
  • Page 16 12 VDC power input — Connect the provided 12 VDC power supply to the rear panel captive screw connectors. When power is connected, the front panel power indicator lights green (see figure on page 8). POWER 1.0A MAX Rear Panel Power Receptacle Ground +12 VDC External...
  • Page 17 IR IN — Connect a remote IR receiver to this 3-pole 3.5 mm captive screw connector to extend the range of the hand control. From SMD 101 IR Receiver IR IN Figure 6. IR In Wiring RS-232 connector (optional) — Connect a host computer or control system to the RS-232 connector or to the local device if pass-through mode is used.

  • Page 18: Smd 101 Rear Panel Reset

    RESET RESET Press and hold Apply power Release Reset button. the Reset button. to the SMD 101. Release, then immediately Reset LED flashes Modes 4 and 5 press and release again. Reset twice or three times. LED flashes, then goes off.

  • Page 19: Smd 101 Power Up Procedure

    SMD 101 Power Up Procedure NOTE: Before powering on the SMD 101, ensure that all necessary devices are connected properly. Devices do not need to be powered. Connect the external power supply to a 100 to 240 VAC supply (see Rear Panel Features on page 9).

  • Page 20: Web-Based User Interface

    Web-based User Interface This section provides information about: Overview of the Web-based User Interface • • Accessing the Web-based User Interface • Page Overview Player Page • • Configuration Page Advanced Configuration Page • • Device Information Page • Status Page Browser Idle •...

  • Page 21: Page Overview

    Page Overview The web interface opens as shown in figure 11 (below). The page contains multiple panels that are collapsed and expanded using the buttons at the top of each panel (see figure 11, An interactive embedded help file is always available by clicking the help icon (see figure 11, ) from any page or panel.

  • Page 22: Player Page

    Player Page Click the Player tab (see figure 13). This page has four panels;   Player Controls Browser , and described in the following sections. Each panel expands or Lists Playlist Editor collapses to provide additional screen space and can have second level tabs. Figure 13.
  • Page 23 Status indicator and Player Controls — Text above the controls (figure 14, ) indicates the current decode state (stopped, paused, or playing). Playing Stopped Figure 14. Player Control Buttons The controls are: Return — If pressed within five seconds after the clip begins, returns to the previous clip or stream and plays.

  • Page 24: Browser

    Source field When a source (clip or stream) loads, this field displays the path and file name. Click ( to the right of the text field to open a dialog displaying paths and file names too long for the field. A source can be loaded by any of these methods: •...

  • Page 25: Browser Panel - Streams

    Browser Panel - Streams tab in the panel displays a list of streams identified on the local Streams Browser subnet the SMD 101 is connected to. NOTE: The compatibility of streams listed in the browser is not assured. Stream compatibility is verified by the SMD 101 only as it is loaded for play. The streams list is generated using information from Session Announcement Protocol (SAP) messages broadcast on the local subnet.

  • Page 26: Browser Panel - Files

    Filter Filters are provided to refine the list of streams viewed in the browser. There are three filters with sub-filters to narrow the list of streams. The default choice for each filter is Source — Limits the browser to streams identified by their source device or location. •...
  • Page 27 In a current session, the folder view is retained after the user collapses the browser, changes tabs within the browser, or changes the page (for example, from Player to Configuration). The default view (top folders expanded and all sub-folders collapsed) is restored each time the web interface is opened or refreshed.

  • Page 28: Lists

    Lists panel features an editable channel list for use with the optional IR remote control Lists (see IR Remote Control on page 56), a drag and drop favorites list for convenient access of frequently played files, and the playback history. By default the player page opens with the panel expanded to the right of the browser.
  • Page 29 To clear an item, select the item, then click . To clear all items, Delete>Delete Selected click Delete>Delete All NOTE: Channel, Favorite and History lists are imported or exported using the panel found on the page of the Configuration Firmware Loader Advanced page.
  • Page 30 Lists Panel – History tab displays a list of previously played clips, playlists, or streams with details of History the data and time the item played and the URI of the item, grouped by time period. Figure 21. Lists Panel, History Tab Fields below the history list show the date and time of the selected item along with the URI.

  • Page 31: Playlist Editor

    Playlist Editor By default, the Player page opens with the open (see figure 22). Playlist Editor Figure 22. Player Page, Playlist Editor Playlists are stored in local media and are found using the files tab of the browser. Select a playlist on the tab of the panel (see figure 22,...
  • Page 32 The playlist title, creator, track title, track duration, and URI of a currently selected clip in the playlist are shown in the   panel. If an attempt is made to add an Playlist Properties unsupported clip, an error message (“unsupported file format”) is presented. NOTE: Playlist level metadata is not supported in M3U, M3U8, and PLS format playlists.
  • Page 33 The track duration, the length of time a clip plays during the playlist, can be shortened or lengthened without changing the original clip. Although a duration can be set beyond the clips original playing time, the transition to the next clip occurs when the clip completes. NOTES: •...

  • Page 34: Configuration Page

    Configuration Page tab provides controls on the global navigation bar to adjust basic Configuration features of the SMD 101. The controls are in four groups; Video Audio On Screen , and accessed from a ribbon toolbar across the top of the screen Display Automation (see figure 24).
  • Page 35 HDMI Output panel Select an output resolution and rate from a list of output timings. When the source (stream or file) resolution or rate differs from the selected output, scaling and frame rate conversion are applied. In addition, you can choose to match the output resolution to the timings of the current stream or file (provided those timings are supported by the SMD 101 and the connected display) or to match the output with optimum timings for the display.

  • Page 36: Audio Configuration

    Audio Configuration The Audio Configuration page (see figure 25) provides information and control of the analog audio output. The controls do not affect embedded audio on the HDMI output. Analog audio can be delayed or muted. A master gain control for the selected audio is provided.

  • Page 37: On Screen Display

    Status Information information that includes stream, network condition, and device information. Extron Electronics 192.168.254.254 SMD 101 Stream Media Decoder FW: 1.20 VIDEO STREAM 0 AUDIO STREAM 0 encoding: h264 video...

  • Page 38: Automation

    Progress Bar Panel The progress bar is similar to the information shown underneath the live confidence display in the   panel. The bar shows the clip or filename and current playback Player Control location. The current playback position is at the left of the progress bar. The total clip length is on the right when a clip is selected and its length is known.
  • Page 39 Screen Saver panel The screen saver activates when there is inactivity. Settings include: — The length of inactivity time (no stream decode, no commands Show Screen Saver: received, and no user input) before the screen saver starts. Click to enable the screen After saver mode, then enter or select the number of seconds of inactivity before the screen saver activates.

  • Page 40: Advanced Configuration Page

    Advanced Configuration Page The Advanced Configuration page provides options that are not frequently changed. The page is is always available, but options are dimmed depending on the current user privileges. It provides initial setup and administrator level configuration. Figure 30. Advanced Configuration Ribbon Connection The Connection Settings page allows configuration of parameters related to the LAN...
  • Page 41 — The MAC address of the connected SMD 101. The address is also • MAC Address: available on the rear panel label. • — Resets all network configuration to default. Reset to Default: • — Saves manual network configuration changes. Save •...

  • Page 42: Firmware Loader

    Serial RS-232 Settings panel This panel provides basic serial port configuration that includes: • — Configures the port to receive SIS commands from an external host controller, Mode: or to pass communication between the "serial pass-through" network port and the serial port.
  • Page 43 Firmware panel • — Displays the active firmware version. Compare the Current Firmware Version: version with the online version on the SMD 101 product page at the Extron website, to determine if you are running the most current firmware. • — This field displays the location of the update Select a firmware file to upload: firmware file.
  • Page 44 The files are saved to the host computer downloads folder and also saved to the SMD 101 local memory nortxe-backup folder. Figure 35. Configuration Files NOTES: • Using Firefox or Chrome, the config files are automatically named box.cfg and saved to both the SMD 101 local memory (in the ip.cfg nortxe‑backup folder( and to the host computer downloads folder (or designated location if...

  • Page 45: Exec/Power Mode

    Exec/Power Mode The Executive and Power Mode page allows configuration of device control and power settings. Figure 36. Exec/Power Mode Page Control Options Panel • — The front panel IR receiver or rear panel IR receiver input can be IR receiver: enabled or both can be disabled.

  • Page 46: Date And Time

    Date and Time The Date and Time page allows automatic sync of the date and time from the connected control device, or provides manual setting of the date and time, timezone, and daylight saving mode. Figure 37. Date and Time Panel —...
  • Page 47 When an admin password and user password are both set, logging in with the user ID and password limits access. Full player control is allowed, but configuration options are limited including: Player Page: • Create a new playlist, but cannot modify or delete an existing playlist. Full player control •...

  • Page 48: Reset Device

    To set, change, or clear a user password you must be logged on as an admin. Click to clear a previous password, then type a password in the Clear User Password: field. If this is the first time a password is set, type the password in the User Password: field.

  • Page 49: Snmp

    SNMP The Simple Network Management Protocol (SNMP) page facilitates the exchange of basic network management information to provide monitoring, control, and to collect error information. Figure 40. SNMP Page SNMP panel • — SNMP is disabled by default. Check this box, then click to enable Enable SNMP Save...

  • Page 50: Device Information Page

    Firmware Build — The specific build number of the firmware. • MAC Address — The Media Access Control (MAC) address of the device. Default Web Version — This number indicates the revision of the SMD 101 embedded • web pages.

  • Page 51: Status Page

    User Defined Information Panel Displays information input by the user including: • — A unique name to identify the device on the network. Device Name — (optional) The location of the device. • Device Location NOTE: The device name and location must begin with an alpha character. Other restrictions are detailed in the help file and tool tips.
  • Page 52 — Total dropped packets for the current source since playback of • Dropped Packets: the stream started. • — Total percentage of dropped packets for the current source since Dropped %: playback of the stream started. • — For transport streams, audio and video streams are combined for this Jitter: value.

  • Page 53: Browser Idle

    Browser Idle To conserve the host computer resources, after 60 minutes, the browser accessing the SMD 101 web interface stops requesting status and video confidence updates. An idle dialog box opens (see below). This feature does not idle or affect SMD 101 operation. It suspends the automatic browser updates for the video confidence display to conserve network and PC resources.

  • Page 54: Advanced Player Configuration

    Advanced Player Configuration The SMD 101 can play video on demand, video from a network share, and video from its own local memory. The following section includes SMD 101 configuration for playing those videos and how to configure the SME 100 for stream discovery that includes the following topics: Loading Content to Local Storage Using SFTP Play Video on Demand...
  • Page 55 Download and install the FileZilla program. After installation, run the program. From the toolbar select File>Site Manager.   dialog opens. Site Manager General Advanced Transfer Settings Charset 192.168.193.165 22022 Host: Port: Protocol: SFTP-SSH File Transfer Protocol Logon Type: Normal admin User: Password: *****...
  • Page 56 (clips, audio, or images) to this folder. • Using SFTP to transfer files to the SMD 101, if the file size exceeds the available space, the file is truncated and is not playable. When working near the capacity limit of the SMD 101, pay close attention to the SFTP client messages for transfer errors.

  • Page 57: Play Video On Demand

    Play Video on Demand The SMD 101 can play video on demand from network shares and local storage supporting the following file types: Video: , and m2ts mov* flv* sdp. NOTE: *Supports files that use H.264 encoding and AAC audio only. Images: , and jpeg...
  • Page 58 Enter a name for the shared file to ease identification in the browser. NOTE: The local name for the shared folder (in this example, ) is MediaShare optional. If the user does not define a name, it defaults to the server folder name. Click if you want the connection to persist.

  • Page 59: Sme 100 Stream Discovery

    SME 100 Stream Discovery For SME 100 stream discovery in the SMD 101 stream browser window (see Browser Panel - Streams on page 19), the SME 100 must have both Stream Control and SAP Control enabled. Figure 49 shows the SME 100 settings. From the SME 100 default web page (see the SME 100 User Guide), select the link, then Encoder Configuration...

  • Page 60: Connecting To Streams Without Sap Announcements

    Connecting to Streams Without SAP Announcements For a source that is not configured for SAP announcements (such as IP cameras), the RTSP (pull) stream URI is entered directly in the field of the SMD 101 player controls. The Source URI prefix (udp in the example below) corresponds to the streaming method. UDP or RTP Connections To connect the SMD 101 to a stream using the destination port of the encoder, use the following template:...
  • Page 61 http:192.168.254.254/web/extron.sdp Add the SME 100 user name and password. http://admin:123456@192.168.254.254/web/extron.sdp Press <Enter> to load the stream. The stream loads. If Load Play is active, the stream begins playing. If Load Play is not active, press play (see Player Controls on page 16) to play the stream. Use the templates below to connect the SMD 101 player to SME 100 encoder streams.

  • Page 62: Ir Remote Control

    IR Remote Control The optional handheld IR remote control provides selection of pre-defined streams and files, and direct control over playback. Features include standard transport controls for play, pause, and stop. Up to 99 pre-configured channels can be directly accessed using the digit buttons.

  • Page 63: Remote Communication And Control

    Remote Communication and Control This section describes SIS programming and control of the SMD 101, including: Connection Options • • LAN (Ethernet) Port Host-to-device Communications • • Command and Response Tables Connection Options The SMD 101 Streaming Media Decoder can be remotely connected via a host computer or other device (such as a control system) attached to the rear panel RS-232 port or LAN port, or the front panel USB Config port.

  • Page 64: Front Panel Configuration Port

    Front Panel Configuration Port Front Panel Features The mini type B USB port is located on the front panel (see page 8). It connects to a host computer for configuration using SIS commands with DataViewer. To connect the SMD 101 to a host computer: NOTE: If an Extron USB device has never been connected to the host computer, prior to connecting the SMD 101 config (USB) port for the first time, you must install and activate the USB driver.

  • Page 65: Lan (Ethernet) Port

    Select Install the software automatically (Recommended) NOTE: You do not need to insert an installation disc. Click Next The PC locates the driver and installs it. When the Completed dialog opens, click to close the wizard. Finish NOTE: The wizard opens only on the first occasion you connect the SMD 101 to a USB port.

  • Page 66: Verbose Mode

    To Establish a Network Connection to the SMD 101: Open a TCP socket to port 23 using the player IP address. NOTE: If the local system administrators have not changed the value, the factory-specified default, 192.168.254.254, is the correct value for this field. The SMD 101 responds with a copyright message including the date, the name of the product, firmware version, part number, and the current date/time.

  • Page 67: Host-To-Device Communications

    The SMD 101 sends the boot and copyright messages under the following circumstances: • If the SMD 101 is off and an RS-232 connection is already set up (the PC is cabled to the SMD 101 and a serial communication program such as HyperTerminal is open), the connected unit sends these messages via RS-232 when first powered on.

  • Page 68: Error Responses

    The Command and Response tables list valid ASCII (for Telnet or RS-232) command codes, the corresponding URL (uniform resource locator) encoded (for Web browsers) command codes, the SMD 101 responses to the host, and a description of the command function or the results of executing the command.

  • Page 69: Simple Control Port Commands - Telnet And Web-Browser Accessible

    Simple Control Port Commands - Telnet and Web-browser Accessible Upper and lower case text can be used interchangeably except where noted. Port 23 is default for Telnet. Port 80 is default for web browsers. They both can be mapped to different ports.

  • Page 70: Symbol Definitions

    Symbol definitions = RS-232 direct access mode = CR/LF (carriage return/line feed) =disabled, =host control, =direct or ¦ = Carriage return (no line feed, hex 0D) access:pass-through) • = Space = Security level: * = Asterisk character (which is a command =network user character, not a variable) =admin user...
  • Page 71 = Off (default) 0 = Input active and timer reset = Crop (not currently supported) = Input inactive, timer running, and = Alternating pixels output active = Alternating lines = Input inactive, timer expired, and output video and sync muted = Crosshatch (grid) = 4x4 crosshatch (grid) X56$...
  • Page 72 X59@ = Player state =stop, =play, =pause X59# = Playback speed ( =normal speed) X59$ = Timecode value HH:MM:SS.DD format DD is decimal seconds up to nine digits. X59^ = File path X59& = Channel preset number ( . Returns ‑1 1‑99 if current source is not a channel preset.

  • Page 73: Command And Response Tables

    Command and Response Tables Basic SIS Commands ASCII command URL Encoded Response Command (host to device) (web) (device to host) Information requests X1!] Firmware version X1!] Firmware and build *Q/q version X1!] Kernel firmware and build **Q/q X1!] ID messaging version ***Q/q ***Q Verbose version info...
  • Page 74 Command and Response Table for Basic SIS Commands (continued) ASCII Command Response Additional Command Description (host to unit) (unit to host) System Commands Configuration Boot1 ] Reboot system Complete system reboot. 1BOOT Cfg1*{config type} ] Save box Save the current 1*{config type}XF configuration configuration...
  • Page 75 Command and Response Table for Basic SIS Commands (continued) ASCII Command Response Additional Command Description (host to unit) (unit to host) Port Assignment NOTES: • Duplicate assignments are not permitted (for example, the telnet and web port assignment cannot be the port# same) and will return the error.
  • Page 76 Command and Response Table for Basic SIS Commands (continued) ASCII Command Response Additional Command Description (host to unit) (unit to host) Direct access port E [ port# ] MD } Set direct access Pmd [ port# ] Set serial pass-through port port map number.
  • Page 77 Command and Response Table for Basic SIS Commands (continued) ASCII Command Response Command Additional Description (host to unit) (unit to host) IP Setup Commands Set unit name E X1@ CN } X1@ ] Set the name of the unit. • Set unit name to CN } X1@ ]...
  • Page 78 Command and Response Table for Basic SIS Commands (continued) ASCII Command Response Command Additional Description (host to unit) (unit to host) Set DNS server E X1$ DI } X1$ ] Set the DNS server IP address. • IP address View DNS server E DI } X1$ ] View the DNS server...
  • Page 79 Command and Response Table for Basic SIS Commands (continued) ASCII Command Response Additional Command Description (host to unit) (unit to host) SNMP (Simple Network Management Protocol) SNMP unit contact Set unit contact E C X60% SNMP } Snmp C* X60%] Sets the unit contact X60% SNMP }...

  • Page 80: Player Sis Commands

    Player SIS Commands Command ASCII command Response Additional description (host to device) (device to host) Password and Security Settings E X3# • X3#] Set administrator = Up to 12 alpha-numeric password characters. View administrator Ipa**** password E • • ] Reset (clear) administrator password...

  • Page 81: Input Configuration

    Command and Response Table for Player SIS Commands (continued) ASCII Command Response Additional Command Description (host to unit) (unit to host) Input Configuration Input video aspect ratio (changes take effect after the next playback start) X50! Set to zoom (fit) E X50! *0ASPR } Aspr X50! *00 ] Sets input...
  • Page 82 Command and Response Table for Player SIS Commands (continued) ASCII Command Response Command Additional Description (host to unit) (unit to host) Playback Play channel X59! at Start playback E S X59! X59# PLYR } PlyrS X59! X59# ] speed X59# . Pause channel X59! .
  • Page 83 Command and Response Table for Player SIS Commands (continued) ASCII Command Response Command Additional Description (host to unit) (unit to host) User Presets View all presets E GTVPR } Get all presets and channel [{...},...] list. E U X59& * X59* TVPR } TvprU X59&...
  • Page 84 Command and Response Table for Player SIS Commands (continued) ASCII Command Response Command Additional Description (host to unit) (unit to host) History E GHIST } Get history, all [{"id":nnn,"date":"YYYY‑MM‑DDTHH:MM:SS", "uri":"filename"},...] (Repeats for all entries). Get history, start E G X60) HIST } Get history from start point [{"id":nnn,"date":"YYYY‑...

  • Page 85: Screen Saver

    Command and Response Table for Player SIS Commands (continued) ASCII Command Response Command Additional Description (host to unit) (unit to host) Set OSD window E D X58* * X52* WNDW } WndwD X58* * X52*] Set OSD info or panel timeout X58* X52*...
  • Page 86 Command and Response Table for Player SIS Commands (continued) ASCII Command Response Command Additional Description (host to unit) (unit to host) Outputs Video Set video output E X3^ VTPO } Vtpo X3^] format E VTPO } X3^] View video output format X52! ] View output rate...

  • Page 87: Reference Information

    Reference Information This section provides information about: Parts and Accessories • • Mounting the SMD 101 SMD 101 Reset Summary • • Optimum Network Share Performance • Configuring Windows 7 for Network File Sharing Copying Config Files Using Internet Explorer • • DataViewer •...

  • Page 88: Rack Mounting

    Rack Mounting For optional rack mounting, do not install the rubber feet. Mount the SMD 101 on a 19 inch universal or basic rack shelf. Follow the instructions included with the rack mount kit to install the SMD 101. UL Rack Mounting Guidelines The following Underwriters Laboratories (UL) guidelines pertain to the safe installation of the SMD 101 in a rack.

  • Page 89: Smd 101 Reset Summary

    SMD 101 Reset Summary The SMD 101 can be reset to default states using the rear panel reset button, the Reset Device page of the user interface, and SIS commands. Each reset affects different configurations and local files, resetting some to factory condition and retaining others. The reset mode summary table below details the activation, results, and purpose of each rear panel activated reset mode.
  • Page 90 The web-based user interface explains what is retained by each reset. The following table outlines configuration settings and files affected by the SIS command and rear panel resets. In general, configuration settings and files can be: • Retained (not affected by the reset). •...

  • Page 91: Optimum Network Share Performance

    Optimum Network Share Performance For optimum performance, the PC used for network file sharing should be a dedicated server. In smaller systems using a desktop PC, the computer must be configured for the task. You may need to allocate additional resources on the PC by setting the following registry key to 3: HKLM\SYSTEM\CurrentControlSet\Services\LanmanServer\Parameters\Size.

  • Page 92: Configuring Windows 7 For Network File Sharing

    Configuring Windows 7 for Network File Sharing The SMD 101 can access shared folders and files of devices on the same network running various operating systems. PCs running Windows 7 must specifically share the folder to make it available to the SMD 101. The following instructions show how to share a folder on the network to make it available to the SMD 101.
  • Page 93 Check the box in the upper left, then click Share this Folder Permissions The Permissions for Media dialog box opens. In the panel, Group or user names: select Everyone In the panel, under the column, check the Permissions for Everyone Allow Read box, then click...
  • Page 94 In the Media Properties dialog, select the tab. Security In the middle of the dialog, click (see above). Edit The Permissions for Media dialog box opens. In the Group or user names: panel, select , then click System SMD 101 • Reference Information...
  • Page 95 In the field, enter , then Enter the object names to select (examples): Everyone click is underlined. Check Names Everyone £ £ ¤ ¤ Click . The Security dialog box opens. In the Permissions for Everyone panel, under the Allow column, if they are not already, make certain , and are checked.
  • Page 96 This completes the folder sharing permissions. Close all open dialog boxes. Next the sharing properties must be configured. In the control panel, click Network and Internet Click Network and Sharing Center Click on the left side of the dialog. Change advanced sharing settings Click on the down arrow icon to expand the option.
  • Page 97 On the expanded Home or Work panel make the following selections: = On • Network Discovery = On • File and Printer Sharing = On • Public Folder Sharing = Enable File Sharing for Devices that use 40- or 56- •...

  • Page 98: Copying Config Files Using Internet Explorer

    Copying Config Files Using Internet Explorer Internet Explorer does not automatically save the SMD 101 config files to the host computer (see Configuration panel on page 37), but attempts to open them instead. The box.cfg and ip.cfg files must be saved using a text file copy. To save a configuration file using IE: Open the web-interface for the SMD 101 (see Accessing the Web-based User...

  • Page 99: Dataviewer

    DataViewer DataViewer is an enhanced terminal emulation program that facilitates analysis of RS-232, USB, and TCP/IP communication with Extron devices. The software allows users to send commands to a device and view the responses in ASCII or hexadecimal format. Command and response logs can be saved in text or HTML format.

  • Page 100: Glossary

    Glossary Advanced Audio Coding (AAC) — A standardized compression and encoding scheme for lossy (low quality) digital audio. Higher bit rates provide higher quality. Part of the MPEG-2 and MPEG-4 specifications. The SMD 101 supports AAC-LC (MPEG-2 part 7, MPEG-4 part 3, sub-part 4 and part 14, MP4 audio). Advanced Video Coding (AVC) —...
  • Page 101 Elementary Stream — Raw H.264 video or raw AAC audio, not wrapped by additional headers. Encoder — A hardware device or software program used to compress (encode) or change a signal from one format to another or convert an analog signal into a digital data stream. The SME 100 is an encoder that converts analog audio and video into digital streams.
  • Page 102 Internet Group Management Protocol (IGMP) — A TCP/IP communications protocol used by hosts and adjacent routers on a network to establish multicast group memberships. When the SMD 101 is connected to a streaming media server, the IGMP multicast protocol is used to pull RTSP streams. The IGMP multicast protocol conserves network bandwidth because the streaming media server only connects to the SMD 101 when the connection to the streaming media server is made by the user.
  • Page 103 Network Address Translation (NAT) — A network protocol that allows multiple devices to have their own, individual, private addresses, but they share one public IP address (IPv4) for connection to the internet or other networks. Network Time Protocol (NTP) — A protocol used for synchronizing the clocks of computer systems over networks.
  • Page 104 Static IP address — An IP address specifically (instead of dynamically [see "DHCP"]) assigned to a device or system in a network configuration. This type of address requires manual configuration of the network device or system and can only be changed manually or by enabling DHCP.
  • Page 105 Extron Warranty Extron Electronics warrants this product against defects in materials and workmanship for a period of three years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option, repair or replace said products or components, to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is returned within the warranty period, with proof of purchase and description of malfunction to: USA, Canada, South America,...
