SMD 101 Reset Summary
The SMD 101 can be reset to default states using the rear panel reset button, the
Reset Device page of the user interface, and SIS commands. Each reset affects different
configurations and local files, resetting some to factory condition and retaining others.
Mode Activation
1
Press and hold the recessed
Reset
rear panel
applying power to the unit.
3
Press and hold the
button for about 3 seconds until
the Reset LED blinks once, then
release and press
within 1 second*.
4
Press and hold the
button for about 6 seconds until
the Power LED blinks twice
(once at 3 seconds, twice at
6 seconds). Then, release and
Reset
press again within 1
second*.
5
Press and hold the
button for about 9 seconds
until the Power LED blinks three
times (once at 3 seconds, twice
at 6 seconds, three times at 9
seconds). Then, release and
Reset
press again within 1
second*.
NOTES:
* = For modes 3, 4, and 5, nothing happens if the momentary press does not occur within 1 second.
•
• Although removable devices and network shares are accessible as part of the user file system, those
temporarily mounted file systems are not affected by reset operations. A mode 1, 3, 4, and 5 reset does
not un-mount removable devices. If required, those devices must be un-mounted manually.
SMD 101 Reset Mode Summary
Result
The SMD 101 reverts to the factory
default firmware for a single power cycle.
button while
Mode 3:
Reset
•
Same as ZXXX SIS command.
•
Reset to defaults, but retains the IP
Reset
again
address and user files.
Reset Mode 4:
•
Sets port mapping back to factory
default.
•
Sets the IP address back to factory
default (192.168.254.254).
•
Sets the subnet mask address back
to the factory default (255.255.0.0).
•
Sets the gateway IP address to the
factory default (0.0.0.0).
•
Turns DHCP off.
•
The Reset LED on the rear panel
of the unit flashes four times in
succession.
Reset Mode 5:
Performs a complete reset to factory
defaults (except the firmware).
•
Does everything mode 4 does.
•
Clears port configurations.
•
Resets all IP options.
•
Clears all user settings.
•
Clears all files from the unit.
•
The Reset LED on the rear panel
of the unit flashes four times in
succession.
Purpose and Notes
If incompatibility issues arise with
user-loaded firmware, use mode 1
to revert to the factory default
firmware for a single power cycle.
All user files and settings are
maintained.
Mode 3 is useful for restoring Auto
video output rate if the display is
unable to support the currently
set rate.
Mode 4 is used to set
IP address information using ARP
and the MAC address.
Mode 5 is useful when wanting to
start over with configuration and
uploading, and also to replace
events.
