Extron electronics Converter CVC 200 Specifications

Specifications — CVC 200 Converter

Video

Gain ............................................... Unity
Bandwidth .................................... 55 MHz (-3 dB)

Video input

Number/signal type ................... 1 component video [HDTV, W-VHS (Y, P
Connectors .................................... 3 BNC female
Nominal level ............................... 1 V p-p for Y of component video
Minimum/maximum levels ...... Y: 0.5 V to 1.5 Vp-p with no offset at unity gain
Impedance .................................... 75 ohms
Horizontal frequency .................. 15.75 kHz to 100 kHz according to selected mode
Vertical frequency ....................... 60 Hz
Return loss .................................... <-25 dB @ 5 MHz
DC offset (max. allowable) ......... ±2 V (maximum)

Video output

Number/signal type ................... 1 RGBHV, RGBS
Connectors .................................... 6 BNC female
Nominal level ............................... 0.7 Vp-p for RGB
Minimum/maximum levels ...... RGB: 0.4 V to 1.0 Vp-p
Impedance .................................... 75 ohms
Return loss .................................... <-30 dB @ 5 MHz
DC offset ....................................... 0.1 V with input at 0 offset

General

Power ............................................. 100 VAC to 240 VAC, 50/60 Hz, 12 watts, internal
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, unvented
Rack mount ................................... Yes, with optional 1U, 9" deep rack shelf (RSU 129, #60-190-01; RSB 129, 60-604-01)
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.6" H x 8.75" W x 9.4" D (1U high, half rack wide)
Product weight ............................. 2.8 lbs (1.3 kg)
Shipping weight ........................... 5 lbs (3 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
1-2
CVC 200 • Specifications
(Y, R-Y, B-Y)] or RGsB
0.3 V p-p for R-Y and B-Y of component video
0.7 V p-p for P P
B R
P P : 0.4 V to 1.0 Vp-p with no offset at unity gain
B R
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
4.1 cm H x 22.2 cm W x 23.9 cm D
(Depth excludes connectors.)
, P ), SMPTE (Y, R-Y, B-Y), and Betacam
R B
(7.53-081507-D6)
®
