4.2.1 Location of DIP switches and RSW switches

Location of DIP switches and RSW rotary switches
• RCI(M)-(1.0-6.0)FSN2(E) units
• RCD-(1.0-3.0)FSN2 units
• RPC-(2.0-6.0)FSN2E units
• RPF(I)-(1.0-2.5)FSN2E units
• RPI(M)-(0.8-6.0)FSN2E (-DU) units
• RPI-(8.0/10.0)FSN2E units
• RPK-(1.0/1.5)FSN(H)2M units
