Chapter E - DIMAX3 DIGITAL SYSTEM ADJUSTMENT
2

PANORAMIC X-RAY BEAM ADJUSTMENT

NOTE
2.1

Removing and attaching the fixed sensor head

Removing the sensor head
E-4 Planmeca Proline CC panoramic x-ray
Switch the unit off after all the checks and adjustments have been performed, before tak-
ing any patient exposures.
Unscrew the bottom cover plate attachment screw with the 4mm allen key and remove the cover
plate.
Figure 1
