Chapter E - DIMAX3 DIGITAL SYSTEM ADJUSTMENT
1
REQUIRED TOOLS
E-2 Planmeca Proline CC panoramic x-ray
•
Alignment ruler (part number 50973). For checking the position of the patient positioning
mechanism.
•
Ball phantom (part number 50971). For checking the position of the patient positioning mech-
anism and the positioning lights.
•
Frankfort plane alignment tool (part number 50977). Used with the ball phantom for checking
the position of the Frankfort plane light.
Alignment ruler
Ball phantom
Frankfort plane
alignment tool
7
9 7
. 5 0
N O
O Y
C A
M E
A N
P L
Technical Manual
