CEPHALOSTAT ADJUSTMENT

9.1

Removing the cassette holder cover

M4x8 BN 5950
M4x4 DIN 7985
Technical Manual
Loosen the two M4x8 BN 5950 bolts on the top of the cover with a 5.5 mm ring spanner. Loosen
the two M4x4 DIN 7985 screws on the bottom of the cover. Pull the cover away from the cassette
holder.
