Chapter C - HELP & ERROR MESSAGES
2

ERROR MESSAGES

ERROR CODE
E r 0 0
The exposure switch was released too early during exposure.
E r 0 1
Short loss of power or drop in line voltage.
E r 0 4
The cassette carriage not in ready position when the exposure switch was pressed.
E r 0 5 Wrong secondary slot selected.
E r 0 6 The rotating unit not in the end sensor (in transversal slicing system mode).
E r 0 7 The rotating unit is not in the ready position.
E r 0 8
The wrong type sensor head (i.e. panoramic type) attached to the cephalostat.
E r 1 0
Overvoltage in tube head.
E r 1 1 Sudden kilovolt drop.
E r 1 2 Tube filament initializing is not done.
E r 1 5
The patient positioning mechanism not calibrated.
E r 2 0
Tube power generator time out. The exposure time is longer than a specified time.
E r 2 1
Up/down motor time out. The vertical carriage does not reach the limit sensor within a specified time.
E r 2 2 Temple rest motor time out.
E r 2 3 Layer adjust motor time out. The layer mechanism does not reach the limit sensor within a specified
time.
E r 2 4
Primary slot motor time out. The slot mechanism does not reach the sensor in specified time.
E r 2 5 Cassette motor time out. The cassette holder mechanism does not reach the limit sensor within a
specified time.
E r 2 6
Rotation motor time out. The rotating unit does not reach the limit sensor in the specified time.
E r 2 7
Cephalostat scanning mechanism time out.
E r 2 8 Panoramic sensor head motor time out. The sensor head does not reach the panoramic position in the
specified time. Or the safety limit switch is pressed and the movement of the sensor head is prevented.
E r 3 0 kV value does not reach given value.
E r 3 1
mA value does not reach given value.
E r 3 2
Tube filament control inoperative.
E r 3 3 Tube filament control inoperative.
E r 4 0 The rotation does not reach the end limit sensor.
E r 4 1 Rotation goes over the end limit sensor.
C-2 Planmeca Proline CC panoramic x-ray
The purpose of the error messages is to make fault-finding easier. The list of the last 50 error
occurrences is of a great help. Please refer to the section "Error history display" on page B-13
how to display the error list.
ERROR MESSAGE EXPLANATION
