Chapter E - DIMAX3 DIGITAL SYSTEM ADJUSTMENT
Adjust the head support angle with the two screws (use 2.5mm allen key) located on the left side
of the mechanism (see Fig. 19 on page E-14 and Fig. 20 below).
90°
Spirit level
Figure 20
Technical Manual
Planmeca Proline CC panoramic x-ray E-15
