Chapter E - DIMAX3 DIGITAL SYSTEM ADJUSTMENT
Lock disk
E-44 Planmeca Proline CC panoramic x-ray
Loosen the four screws located on the lock disc.
Figure 76
Loosen the lock disc attachment screw with the 3mm allen key and remove the lock disc.
Figure 77
