Cephalostat Adjustment; Preparations Before Adjustments - Planmeca Proline CC Technical Manual

6

CEPHALOSTAT ADJUSTMENT

NOTE
6.1

Preparations before adjustments

4
CEPH
Technical Manual
Switch the unit off after all the checks and adjustments have been performed, before tak-
ing any patient exposures.
Press the ceph mode selection key to enter the ceph mode if you are not already in it. The rotat-
ing unit will move automatically to the correct position for taking cephalometric exposures. The
latest used image area will be automatically selected.
Remove the inner cover from tube head assembly. Four screws hold the tube head cover in posi-
tion, these are located at the rear of the tube head assembly.
Tube head cover
Figure 67
Rotate the cephalostat head support to the lateral ceph position. Remove the ear posts.
Chapter E - DIMAX3 DIGITAL SYSTEM ADJUSTMENT
Tube head
assembly
Planmeca Proline CC panoramic x-ray E-39
