Chapter
D - ADJUSTMENT & CALIBRATION
9.5

Soft tissue filter positioning light calibration and adjustment

Soft tissue filter positioning light calibration
D-40 Planmeca Proline CC panoramic x-ray
Enter the service mode (see section "How to enter/exit the service mode" on page B-6).
Orientate the Cephalometric beam alignment tool so that it is vertical and then place it in the
cephalometric cassette holder. Position it so that it is on the left of the cassette holder.
Cassette
holder
4
Beam
alignment
tool
PLANMECA PM 2002 Proline Cephalostat 18x24
Figure 45
Press the CTL-key, the light beam position number will appear on the main display.
Slide the light to the right as far as possible and check that the position number on the display is
>10. If it is not, adjust the light assembly position with the light assembly lever (Fig. 46, 1) so that
the number will be >10.
2
4 5
PLANMECA PM 2002 Proline CC Cephalostat 18x24
Figure 46
Press the Vertical sector selection D key. The text "CAL" will appear on the main display and the
rotating unit and cassette carriage will move automatically to the cephalometric mode position.
You are now in the soft tissue filter positioning light calibration mode.
Slide the patient positioning light to left as far as possible. The beam from the soft tissue filter
positioning light should strike the line on the beam alignment tool marked "Positioning light 0mm"
(Fig. 46, 2).
5
No. 652232
3
0 - 48mm
No.652232
4
1
Technical Manual
