Chapter
D - ADJUSTMENT & CALIBRATION
If the distances from the middle ball to the center of the tenth ball on both the right and left are
less than 118mm then the patient positioning mechanism is too far forward and must be moved
backwards (Fig. 19).
Right-hand side
Film
Less than 118mm
Less than 118mm
Figure 19
Technical Manual
Planmeca Proline CC panoramic x-ray D-13
