Chapter H - PARTS REPLACEMENT & REPAIR
3.6

Layer hold limits

a)
b)
c)
d)
3.7

Primary position detector

a)
b)
c)
d)
H-6 Planmeca Proline CC panoramic x-ray
Open the cover of the lover shelf
Unscrew two fixing screws
Remove the connector
After installing new PCB check the limits and adjust if necessary
Remove the front cover of tube head
Unscrew the two fixing screws.
Remove the connector
After installing new PCB check the radiation beam with all slots and adjust if necessary.
