MVI69-GSC ♦ CompactLogix or MicroLogix Platform
Generic ASCII Serial Communication Module
1.2

Package Contents

The following components are included with your MVI69-GSC module, and are all
required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following items are present.
Qty. Part Name
1 MVI69-GSC Module
1 Cable
3 Cable
2 Adapter
If any of these components are missing, please contact ProSoft Technology Support for
replacement parts.
ProSoft Technology, Inc.
Part Number Part Description
MVI69-GSC Generic ASCII Serial Communication
Module
Cable #15, RS232 For RS232 Connection to the CFG Port
Null Modem
For DB9 Connection to Module's Port
Cable #14, RJ45 to
DB9 Male Adapter
cable
1454-9F Two Adapters, DB9 Female to Screw
Terminal. For RS422 or RS485
Connections to Port 1 and 2 of the Module
Contents
User Manual
Page 9 of 83
