MVI69-GSC ♦ CompactLogix or MicroLogix Platform
Generic ASCII Serial Communication Module

5.1.2 Hardware Specifications

Specification
Dimensions
Current Load
Operating Temp.
Storage Temp.
Relative Humidity
LED Indicators
CFG Port (CFG)
App Ports (P1,P2)
(Serial modules)
Shipped with Unit
ProSoft Technology, Inc.
Description
Standard 1769 Single-slot module
800 mA max @ 5 VDC
Power supply distance rating of 2 (L43 and L45
installations on first 2 slots of 1769 bus)
32° F to 140° F (0° C to 60°C)
-40° F to 185° F (-40° C to 85° C)
5% to 95% (with no condensation)
Battery and Module Status
Application Status
Serial Port Activity
CFG Port Activity
RJ45 (DB-9F with supplied cable)
RS-232 only
No hardware handshaking
RS-232, RS-485 or RS-422 (jumper selectable)
RJ45 (DB-9F with supplied cable)
RS-232 handshaking configurable
500V Optical isolation from backplane
RJ45 to DB-9M cables for each port
6-foot RS-232 configuration Cable
Contents
User Manual
