2.1.4 Adding Multiple Modules (Optional)

Important: If your application requires more than one MVI69-GSC module in the same project, follow the

steps below.

In the I/O Configuration folder, click the right mouse button to open a shortcut menu,

and then choose New Module.

Select 1769-MODULE

Fill the module properties as follows:
