MVI69-GSC ♦ CompactLogix or MicroLogix Platform
Generic ASCII Serial Communication Module
5.4

GSC Database Definition

This section contains a listing of the internal database of the MVI69-GSC module. This
information can be used to interface other devices to the data contained in the module.
Register Range
0 to 4999
5000 to 5009
5010 to 5039
5040 to 5069
5070 to 5869
5870 to 6669
6670 to 6702
6703 to 6749
6750 to 6759
6760 to 6769
The User Data area holds data collected from other nodes on the network (master read
commands) or data received from the processor (write blocks). Additionally, this data
area is used as a data source for the processor (read blocks) or other nodes on the
network (write commands).
Detailed definition of the miscellaneous status data area and configuration data areas
can be found in the Reference chapter.
ProSoft Technology, Inc.
Content
User Data
Backplane Configuration
Port 1 Setup
Port 2 Setup
Port 1 Commands
Port 2 Commands
Misc. Status Data
Reserved
Port 1 Status Data
Port 2 Status Data
Contents
User Manual
Size
5000
10
30
30
800
800
32
10
10
