2.7

Changing Parameters During Operation

A copy of the module's configuration data is mapped in the module's database as
described in the following table. These values are initialized when the module first
receives its configuration from the configuration file.
The configuration file is located in the module as well as website. With a new module,
ProSoft recommends that you download the configuration file from the module for
editing. Refer to the next topic for information on transferring the configuration file.
Function Name
Data Transfer General Module
Configuration
Serial Port Port Configuration These sections define the characteristics of each of the
Drivers
ProSoft Technology, Inc.
Description
This section of the configuration data contains the module
configuration data that defines the data transfer between the
module and the CompactLogix processor.
Generic ASCII Serial communication ports on the module.
These parameters must be sent correctly for proper module
operation.
