2.1 MVI69-GSC Sample Add-On Instruction Import Procedure
Note: this section only applies if you are using RSLogix 5000 version 16 or higher. If you are configuring the
MVI69-GSC module with an earlier version of RSLogix 5000, please refer to 69GSC - Installing and
Configuring the Module with a CompactLogix Processor (page 44).
The following file is required before you start this procedure. You can download it from
www.prosoft-technology.com.
File Name
AOI69GSC.L5X

2.1.1 Create a new RSLogix5000 project

1 Open the F
2 Select R
EVISION
ProSoft Technology, Inc.
Description
L5X file containing Add-On instruction, user defined data types, data
objects and ladder logic required to set up the MVI69-GSC module
menu, and then choose N
ILE
16
...
EW
